CADBase Platform API reference

This is the API documentation for CADBase, an open-source platform for storing, versioning, and exchanging engineering data.

Data is organized around component modifications with file sets — so one modification can serve several CAD, CAE, and CAM systems at once. The API lets you manage components, upload and retrieve file sets, work with revisions, and share data across teams.

API Endpoints
# Regional endpoints, same schema.
# Europe: https://api.cadbase.rs/graphql
# Russia: https://api.cadbase.ru/graphql
# Asia:   https://api.cadbase.org/graphql
Contact

API Support

support@cadbase.rs

License

Dual-licensed: AGPL v3 or Commercial

Terms of Service

English · Russian · Chinese

Authorization token

The main API of CADBase is GraphQL. The REST API is only used to obtain an authorization token.

Get a token from the https://api.cadbase.rs/login endpoint.

For GraphQL requests, pass it in the Authorization header:

Authorization: "Bearer YOUR_TOKEN"

Request:
curl \
-X POST \
-H "Content-Type: application/json" \
-d '{
  "user": {
    "username": "YOUR_USERNAME",
    "password": "YOUR_PASSWORD"
  }
}' \
https://api.cadbase.rs/login
Response:
{
  "bearer": "YOUR_TOKEN"
}

API Keys

In addition to JWT bearer tokens, CADBase supports API keys for long-lived, machine-to-machine access. API keys are useful for:

  • integrations with CAD/CAE/CAM, PLM and ERP systems;
  • automated data exchange between CADBase and external tools;
  • scripts, batch operations and scheduled jobs.

An API key is a 32-character alphanumeric string. Only a SHA-256 hash is stored in the database — the raw key is shown only once, at creation time. Store it somewhere safe; it can't be recovered later.

By default, an API key is valid for 1 year. You can set a custom expiration date when creating the key. Dates in the past are rejected.

To authenticate a request, pass the API key in the X-API-Key header instead of Authorization:

X-API-Key: YOUR_API_KEY

Each request using a valid API key updates the key's lastUsedAt timestamp. Inactive, expired, or revoked keys return Unauthorized.

Request:
# Create a new API key
mutation CreateApiKey($name: String!, $expiresAt: DateTime) {
  createApiKey(name: $name, expiresAt: $expiresAt)
}
Response:
{
  "data": {
    "createApiKey": "aB3xK9mP2qR7sT1uV4wY6zL8nM0cD5eF"
  }
}
Request:
# Authenticated request with API key
curl \
-X POST \
-H "Content-Type: application/json" \
-H "X-API-Key: YOUR_API_KEY" \
-d '{ "query": "{ myself { uuid username } }" }' \
https://api.cadbase.rs/graphql

Queries

apiKey

Response

Returns an ApiKeyData!

Arguments
Name Description
keyId - Int!

Example

Query
query apiKey($keyId: Int!) {
  apiKey(keyId: $keyId) {
    id
    userUuid
    name
    lastUsedAt
    expiresAt
    isActive
    createdAt
  }
}
Variables
{"keyId": 987}
Response
{
  "data": {
    "apiKey": {
      "id": 987,
      "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "name": "xyz789",
      "lastUsedAt": "2007-12-03T10:15:30Z",
      "expiresAt": "2007-12-03T10:15:30Z",
      "isActive": false,
      "createdAt": "2007-12-03T10:15:30Z"
    }
  }
}
Queries

apiKeys

Response

Returns [ApiKeyData!]!

Example

Query
query apiKeys {
  apiKeys {
    id
    userUuid
    name
    lastUsedAt
    expiresAt
    isActive
    createdAt
  }
}
Response
{
  "data": {
    "apiKeys": [
      {
        "id": 987,
        "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "name": "xyz789",
        "lastUsedAt": "2007-12-03T10:15:30Z",
        "expiresAt": "2007-12-03T10:15:30Z",
        "isActive": true,
        "createdAt": "2007-12-03T10:15:30Z"
      }
    ]
  }
}
Queries

companies

Response

Returns [ShowCompanyShort!]!

Arguments
Name Description
args - IptCompaniesArg
paginate - IptPaginate

Example

Query
query companies(
  $args: IptCompaniesArg,
  $paginate: IptPaginate
) {
  companies(
    args: $args,
    paginate: $paginate
  ) {
    uuid
    shortname
    inn
    description
    imageFile {
      ...DownloadFileFragment
    }
    region {
      ...RegionTranslateListFragment
    }
    companyType {
      ...CompanyTypeTranslateListFragment
    }
    typeAccess {
      ...TypeAccessTranslateListFragment
    }
    isSupplier
    isFollowed
    createdAt
    updatedAt
  }
}
Variables
{
  "args": IptCompaniesArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "companies": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "shortname": "abc123",
        "inn": "xyz789",
        "description": "xyz789",
        "imageFile": DownloadFile,
        "region": RegionTranslateList,
        "companyType": CompanyTypeTranslateList,
        "typeAccess": TypeAccessTranslateList,
        "isSupplier": true,
        "isFollowed": false,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

company

Response

Returns a CompanyAndRelatedData!

Arguments
Name Description
companyUuid - UUID!

Example

Query
query company($companyUuid: UUID!) {
  company(companyUuid: $companyUuid) {
    uuid
    orgname
    shortname
    inn
    phone
    email
    description
    address
    siteUrl
    timeZone
    ownerUser {
      ...ShowUserShortFragment
    }
    imageFile {
      ...DownloadFileFragment
    }
    region {
      ...RegionTranslateListFragment
    }
    companyRepresents {
      ...CompanyRepresentAndRelatedDataFragment
    }
    companyType {
      ...CompanyTypeTranslateListFragment
    }
    companyCertificates {
      ...CompanyCertificateAndFileFragment
    }
    companySpecs {
      ...SpecTranslateListFragment
    }
    typeAccess {
      ...TypeAccessTranslateListFragment
    }
    isSupplier
    isEmailVerified
    subscribers
    isFollowed
    createdAt
    updatedAt
  }
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "company": {
      "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "orgname": "xyz789",
      "shortname": "abc123",
      "inn": "xyz789",
      "phone": "abc123",
      "email": "abc123",
      "description": "xyz789",
      "address": "xyz789",
      "siteUrl": "xyz789",
      "timeZone": "abc123",
      "ownerUser": ShowUserShort,
      "imageFile": DownloadFile,
      "region": RegionTranslateList,
      "companyRepresents": [
        CompanyRepresentAndRelatedData
      ],
      "companyType": CompanyTypeTranslateList,
      "companyCertificates": [CompanyCertificateAndFile],
      "companySpecs": [SpecTranslateList],
      "typeAccess": TypeAccessTranslateList,
      "isSupplier": false,
      "isEmailVerified": true,
      "subscribers": 987,
      "isFollowed": true,
      "createdAt": NaiveDateTime,
      "updatedAt": NaiveDateTime
    }
  }
}
Queries

companyMembers

Response

Returns [CompanyMemberAndRelatedData!]!

Arguments
Name Description
companyUuid - UUID!

Example

Query
query companyMembers($companyUuid: UUID!) {
  companyMembers(companyUuid: $companyUuid) {
    companyUuid
    user {
      ...ShowUserShortFragment
    }
    companyRole {
      ...RoleMemberAndRelatedDataFragment
    }
    isEnabled
    createdAt
    updatedAt
  }
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "companyMembers": [
      {
        "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "user": ShowUserShort,
        "companyRole": RoleMemberAndRelatedData,
        "isEnabled": false,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

companyRepresentTypes

Response

Returns [RepresentationTypeTranslateList!]!

Example

Query
query companyRepresentTypes {
  companyRepresentTypes {
    representationTypeId
    langId
    representationType
  }
}
Response
{
  "data": {
    "companyRepresentTypes": [
      {
        "representationTypeId": 123,
        "langId": 987,
        "representationType": "abc123"
      }
    ]
  }
}
Queries

companyRepresents

Response

Returns [CompanyRepresentAndRelatedData!]!

Arguments
Name Description
args - IptCompanyRepresentsArg!
paginate - IptPaginate

Example

Query
query companyRepresents(
  $args: IptCompanyRepresentsArg!,
  $paginate: IptPaginate
) {
  companyRepresents(
    args: $args,
    paginate: $paginate
  ) {
    uuid
    companyUuid
    region {
      ...RegionTranslateListFragment
    }
    representationType {
      ...RepresentationTypeTranslateListFragment
    }
    name
    address
    phone
  }
}
Variables
{
  "args": IptCompanyRepresentsArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "companyRepresents": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "region": RegionTranslateList,
        "representationType": RepresentationTypeTranslateList,
        "name": "xyz789",
        "address": "xyz789",
        "phone": "xyz789"
      }
    ]
  }
}
Queries

companyRoles

Response

Returns [RoleMemberAndRelatedData!]!

Arguments
Name Description
companyUuid - UUID!

Example

Query
query companyRoles($companyUuid: UUID!) {
  companyRoles(companyUuid: $companyUuid) {
    role {
      ...RoleMemberTranslateListFragment
    }
    permissions {
      ...PermissionTranslateListFragment
    }
  }
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "companyRoles": [
      {
        "role": RoleMemberTranslateList,
        "permissions": [PermissionTranslateList]
      }
    ]
  }
}
Queries

companySpecs

Response

Returns [SpecTranslateList!]!

Arguments
Name Description
companyUuid - UUID!
paginate - IptPaginate

Example

Query
query companySpecs(
  $companyUuid: UUID!,
  $paginate: IptPaginate
) {
  companySpecs(
    companyUuid: $companyUuid,
    paginate: $paginate
  ) {
    specId
    langId
    spec
    parentSpec {
      ...SpecTranslateListFragment
    }
  }
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paginate": IptPaginate
}
Response
{
  "data": {
    "companySpecs": [
      {
        "specId": 123,
        "langId": 987,
        "spec": "abc123",
        "parentSpec": SpecTranslateList
      }
    ]
  }
}
Queries

companyTypes

Response

Returns [CompanyTypeTranslateList!]!

Example

Query
query companyTypes {
  companyTypes {
    companyTypeId
    langId
    name
    shortname
  }
}
Response
{
  "data": {
    "companyTypes": [
      {
        "companyTypeId": 987,
        "langId": 987,
        "name": "abc123",
        "shortname": "abc123"
      }
    ]
  }
}
Queries

component

Response

Returns a ComponentAndRelatedData!

Arguments
Name Description
componentUuid - UUID!

Example

Query
query component($componentUuid: UUID!) {
  component(componentUuid: $componentUuid) {
    uuid
    parentComponentUuid
    name
    description
    imageFile {
      ...DownloadFileFragment
    }
    ownerUser {
      ...ShowUserShortFragment
    }
    typeAccess {
      ...TypeAccessTranslateListFragment
    }
    componentType {
      ...ComponentTypeTranslateListFragment
    }
    actualStatus {
      ...ActualStatusTranslateListFragment
    }
    isBase
    subscribers
    isFollowed
    createdAt
    updatedAt
    licenses {
      ...LicenseFragment
    }
    componentParams {
      ...ComponentParamWithTranslationFragment
    }
    paramsCount
    files {
      ...ShowFileRelatedDataFragment
    }
    filesCount
    componentSpecs {
      ...SpecTranslateListFragment
    }
    componentKeywords {
      ...KeywordFragment
    }
    componentModifications {
      ...ComponentModificationAndRelatedDataFragment
    }
    modificationsCount
    componentSuppliers {
      ...ComponentSupplierRelatedDataFragment
    }
    suppliersCount
    componentStandards {
      ...ShowStandardShortFragment
    }
    standardsCount
  }
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "component": {
      "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "parentComponentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "name": "abc123",
      "description": "xyz789",
      "imageFile": DownloadFile,
      "ownerUser": ShowUserShort,
      "typeAccess": TypeAccessTranslateList,
      "componentType": ComponentTypeTranslateList,
      "actualStatus": ActualStatusTranslateList,
      "isBase": false,
      "subscribers": 123,
      "isFollowed": false,
      "createdAt": NaiveDateTime,
      "updatedAt": NaiveDateTime,
      "licenses": [License],
      "componentParams": [ComponentParamWithTranslation],
      "paramsCount": 987,
      "files": [ShowFileRelatedData],
      "filesCount": 123,
      "componentSpecs": [SpecTranslateList],
      "componentKeywords": [Keyword],
      "componentModifications": [
        ComponentModificationAndRelatedData
      ],
      "modificationsCount": 123,
      "componentSuppliers": [
        ComponentSupplierRelatedData
      ],
      "suppliersCount": 987,
      "componentStandards": [ShowStandardShort],
      "standardsCount": 987
    }
  }
}
Queries

componentActualStatuses

Response

Returns [ActualStatusTranslateList!]!

Arguments
Name Description
filter - [Int!]

Example

Query
query componentActualStatuses($filter: [Int!]) {
  componentActualStatuses(filter: $filter) {
    actualStatusId
    langId
    name
  }
}
Variables
{"filter": [987]}
Response
{
  "data": {
    "componentActualStatuses": [
      {
        "actualStatusId": 987,
        "langId": 987,
        "name": "abc123"
      }
    ]
  }
}
Queries

componentFiles

Response

Returns [DownloadFile!]!

Arguments
Name Description
args - IptComponentFilesArg!
paginate - IptPaginate

Example

Query
query componentFiles(
  $args: IptComponentFilesArg!,
  $paginate: IptPaginate
) {
  componentFiles(
    args: $args,
    paginate: $paginate
  ) {
    uuid
    hash
    sha256Hash
    filename
    filesize
    downloadUrl
  }
}
Variables
{
  "args": IptComponentFilesArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "componentFiles": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "hash": "abc123",
        "sha256Hash": "abc123",
        "filename": "abc123",
        "filesize": 123,
        "downloadUrl": "xyz789"
      }
    ]
  }
}
Queries

componentFilesList

Response

Returns [ShowFileRelatedData!]!

Arguments
Name Description
args - IptComponentFilesArg!
sort - IptSort
paginate - IptPaginate

Example

Query
query componentFilesList(
  $args: IptComponentFilesArg!,
  $sort: IptSort,
  $paginate: IptPaginate
) {
  componentFilesList(
    args: $args,
    sort: $sort,
    paginate: $paginate
  ) {
    uuid
    filename
    revision
    commitMsg
    parentFileUuid
    ownerUser {
      ...ShowUserShortFragment
    }
    contentType
    filesize
    program {
      ...ProgramFragment
    }
    hash
    sha256Hash
    downloadUrl
    createdAt
    updatedAt
  }
}
Variables
{
  "args": IptComponentFilesArg,
  "sort": IptSort,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "componentFilesList": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "filename": "abc123",
        "revision": 123,
        "commitMsg": "abc123",
        "parentFileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "ownerUser": ShowUserShort,
        "contentType": "xyz789",
        "filesize": 123,
        "program": Program,
        "hash": "abc123",
        "sha256Hash": "xyz789",
        "downloadUrl": "abc123",
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

componentKeywords

Response

Returns [Keyword!]!

Arguments
Name Description
componentUuid - UUID!
paginate - IptPaginate

Example

Query
query componentKeywords(
  $componentUuid: UUID!,
  $paginate: IptPaginate
) {
  componentKeywords(
    componentUuid: $componentUuid,
    paginate: $paginate
  ) {
    id
    keyword
  }
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paginate": IptPaginate
}
Response
{
  "data": {
    "componentKeywords": [
      {"id": 123, "keyword": "xyz789"}
    ]
  }
}
Queries

componentModificationFiles

Response

Returns [DownloadFile!]!

Arguments
Name Description
args - IptModificationFilesArg!
paginate - IptPaginate

Example

Query
query componentModificationFiles(
  $args: IptModificationFilesArg!,
  $paginate: IptPaginate
) {
  componentModificationFiles(
    args: $args,
    paginate: $paginate
  ) {
    uuid
    hash
    sha256Hash
    filename
    filesize
    downloadUrl
  }
}
Variables
{
  "args": IptModificationFilesArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "componentModificationFiles": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "hash": "abc123",
        "sha256Hash": "xyz789",
        "filename": "xyz789",
        "filesize": 987,
        "downloadUrl": "abc123"
      }
    ]
  }
}
Queries

componentModificationFilesList

Response

Returns [ShowFileRelatedData!]!

Arguments
Name Description
args - IptModificationFilesArg!
sort - IptSort
paginate - IptPaginate

Example

Query
query componentModificationFilesList(
  $args: IptModificationFilesArg!,
  $sort: IptSort,
  $paginate: IptPaginate
) {
  componentModificationFilesList(
    args: $args,
    sort: $sort,
    paginate: $paginate
  ) {
    uuid
    filename
    revision
    commitMsg
    parentFileUuid
    ownerUser {
      ...ShowUserShortFragment
    }
    contentType
    filesize
    program {
      ...ProgramFragment
    }
    hash
    sha256Hash
    downloadUrl
    createdAt
    updatedAt
  }
}
Variables
{
  "args": IptModificationFilesArg,
  "sort": IptSort,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "componentModificationFilesList": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "filename": "xyz789",
        "revision": 123,
        "commitMsg": "xyz789",
        "parentFileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "ownerUser": ShowUserShort,
        "contentType": "abc123",
        "filesize": 123,
        "program": Program,
        "hash": "abc123",
        "sha256Hash": "abc123",
        "downloadUrl": "abc123",
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

componentModificationFilesOfFileset

Response

Returns [ShowFileRelatedData!]!

Arguments
Name Description
args - IptFileOfFilesetArg!
sort - IptSort
paginate - IptPaginate

Example

Query
query componentModificationFilesOfFileset(
  $args: IptFileOfFilesetArg!,
  $sort: IptSort,
  $paginate: IptPaginate
) {
  componentModificationFilesOfFileset(
    args: $args,
    sort: $sort,
    paginate: $paginate
  ) {
    uuid
    filename
    revision
    commitMsg
    parentFileUuid
    ownerUser {
      ...ShowUserShortFragment
    }
    contentType
    filesize
    program {
      ...ProgramFragment
    }
    hash
    sha256Hash
    downloadUrl
    createdAt
    updatedAt
  }
}
Variables
{
  "args": IptFileOfFilesetArg,
  "sort": IptSort,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "componentModificationFilesOfFileset": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "filename": "xyz789",
        "revision": 987,
        "commitMsg": "abc123",
        "parentFileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "ownerUser": ShowUserShort,
        "contentType": "xyz789",
        "filesize": 123,
        "program": Program,
        "hash": "xyz789",
        "sha256Hash": "xyz789",
        "downloadUrl": "xyz789",
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

componentModificationFilesetFiles

Response

Returns [DownloadFile!]!

Arguments
Name Description
args - IptFileOfFilesetArg!
paginate - IptPaginate

Example

Query
query componentModificationFilesetFiles(
  $args: IptFileOfFilesetArg!,
  $paginate: IptPaginate
) {
  componentModificationFilesetFiles(
    args: $args,
    paginate: $paginate
  ) {
    uuid
    hash
    sha256Hash
    filename
    filesize
    downloadUrl
  }
}
Variables
{
  "args": IptFileOfFilesetArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "componentModificationFilesetFiles": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "hash": "abc123",
        "sha256Hash": "xyz789",
        "filename": "xyz789",
        "filesize": 123,
        "downloadUrl": "abc123"
      }
    ]
  }
}
Queries

componentModificationFilesets

Response

Returns [FilesetProgramRelatedData!]!

Arguments
Name Description
args - IptFilesetProgramArg!

Example

Query
query componentModificationFilesets($args: IptFilesetProgramArg!) {
  componentModificationFilesets(args: $args) {
    uuid
    modificationUuid
    program {
      ...ProgramFragment
    }
    files {
      ...ShowFileRelatedDataFragment
    }
    filesCount
  }
}
Variables
{"args": IptFilesetProgramArg}
Response
{
  "data": {
    "componentModificationFilesets": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "program": Program,
        "files": [ShowFileRelatedData],
        "filesCount": 987
      }
    ]
  }
}
Queries

componentModifications

Response

Returns [ComponentModificationAndRelatedData!]!

Arguments
Name Description
componentUuid - UUID!
filter - [UUID!]
sort - IptSort
paginate - IptPaginate

Example

Query
query componentModifications(
  $componentUuid: UUID!,
  $filter: [UUID!],
  $sort: IptSort,
  $paginate: IptPaginate
) {
  componentModifications(
    componentUuid: $componentUuid,
    filter: $filter,
    sort: $sort,
    paginate: $paginate
  ) {
    uuid
    componentUuid
    parentModificationUuid
    modificationName
    description
    actualStatus {
      ...ActualStatusTranslateListFragment
    }
    createdAt
    updatedAt
    filesetsForProgram {
      ...FilesetProgramRelatedDataFragment
    }
    filesetsCount
    modificationParams {
      ...ModificationParamWithTranslationFragment
    }
    paramsCount
    files {
      ...ShowFileRelatedDataFragment
    }
    filesCount
  }
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filter": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ],
  "sort": IptSort,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "componentModifications": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "parentModificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "modificationName": "xyz789",
        "description": "abc123",
        "actualStatus": ActualStatusTranslateList,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime,
        "filesetsForProgram": [FilesetProgramRelatedData],
        "filesetsCount": 987,
        "modificationParams": [
          ModificationParamWithTranslation
        ],
        "paramsCount": 987,
        "files": [ShowFileRelatedData],
        "filesCount": 123
      }
    ]
  }
}
Queries

componentSpecs

Response

Returns [SpecTranslateList!]!

Arguments
Name Description
componentUuid - UUID!
paginate - IptPaginate

Example

Query
query componentSpecs(
  $componentUuid: UUID!,
  $paginate: IptPaginate
) {
  componentSpecs(
    componentUuid: $componentUuid,
    paginate: $paginate
  ) {
    specId
    langId
    spec
    parentSpec {
      ...SpecTranslateListFragment
    }
  }
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paginate": IptPaginate
}
Response
{
  "data": {
    "componentSpecs": [
      {
        "specId": 123,
        "langId": 987,
        "spec": "xyz789",
        "parentSpec": SpecTranslateList
      }
    ]
  }
}
Queries

componentSuppliers

Response

Returns [ComponentSupplierRelatedData!]!

Arguments
Name Description
componentUuid - UUID!
paginate - IptPaginate

Example

Query
query componentSuppliers(
  $componentUuid: UUID!,
  $paginate: IptPaginate
) {
  componentSuppliers(
    componentUuid: $componentUuid,
    paginate: $paginate
  ) {
    supplier {
      ...SlimCompanyFragment
    }
    componentUuid
    description
  }
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paginate": IptPaginate
}
Response
{
  "data": {
    "componentSuppliers": [
      {
        "supplier": SlimCompany,
        "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "description": "xyz789"
      }
    ]
  }
}
Queries

componentTypes

Response

Returns [ComponentTypeTranslateList!]!

Arguments
Name Description
filter - [Int!]

Example

Query
query componentTypes($filter: [Int!]) {
  componentTypes(filter: $filter) {
    componentTypeId
    langId
    componentType
  }
}
Variables
{"filter": [987]}
Response
{
  "data": {
    "componentTypes": [
      {
        "componentTypeId": 987,
        "langId": 987,
        "componentType": "abc123"
      }
    ]
  }
}
Queries

components

Response

Returns [ShowComponentShort!]!

Arguments
Name Description
args - IptComponentsArg
sort - IptSort
paginate - IptPaginate

Example

Query
query components(
  $args: IptComponentsArg,
  $sort: IptSort,
  $paginate: IptPaginate
) {
  components(
    args: $args,
    sort: $sort,
    paginate: $paginate
  ) {
    uuid
    name
    description
    imageFile {
      ...DownloadFileFragment
    }
    ownerUser {
      ...ShowUserShortFragment
    }
    typeAccess {
      ...TypeAccessTranslateListFragment
    }
    componentType {
      ...ComponentTypeTranslateListFragment
    }
    actualStatus {
      ...ActualStatusTranslateListFragment
    }
    isBase
    isFollowed
    createdAt
    updatedAt
    licenses {
      ...LicenseFragment
    }
    files {
      ...DownloadFileFragment
    }
    componentSuppliers {
      ...ComponentSupplierRelatedDataFragment
    }
  }
}
Variables
{
  "args": IptComponentsArg,
  "sort": IptSort,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "components": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "name": "abc123",
        "description": "abc123",
        "imageFile": DownloadFile,
        "ownerUser": ShowUserShort,
        "typeAccess": TypeAccessTranslateList,
        "componentType": ComponentTypeTranslateList,
        "actualStatus": ActualStatusTranslateList,
        "isBase": false,
        "isFollowed": false,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime,
        "licenses": [License],
        "files": [DownloadFile],
        "componentSuppliers": [
          ComponentSupplierRelatedData
        ]
      }
    ]
  }
}
Queries

decodeToken

Response

Returns a Claims!

Example

Query
query decodeToken {
  decodeToken {
    iss
    username
    sub
    iat
    exp
    programId
  }
}
Response
{
  "data": {
    "decodeToken": {
      "iss": "abc123",
      "username": "xyz789",
      "sub": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "iat": "xyz789",
      "exp": "abc123",
      "programId": 123
    }
  }
}
Queries

discussionComments

Response

Returns [DiscussionCommentData!]!

Arguments
Name Description
args - IptDiscussionCommentsArg!
sort - IptSort
paginate - IptPaginate

Example

Query
query discussionComments(
  $args: IptDiscussionCommentsArg!,
  $sort: IptSort,
  $paginate: IptPaginate
) {
  discussionComments(
    args: $args,
    sort: $sort,
    paginate: $paginate
  ) {
    uuid
    discussionUuid
    parentCommentUuid
    author {
      ...ShowUserShortFragment
    }
    messageContent
    isEdited
    isHidden
    createdAt
    updatedAt
    repliesCount
    replies {
      ...DiscussionCommentDataFragment
    }
  }
}
Variables
{
  "args": IptDiscussionCommentsArg,
  "sort": IptSort,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "discussionComments": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "discussionUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "parentCommentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "author": ShowUserShort,
        "messageContent": "xyz789",
        "isEdited": true,
        "isHidden": true,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime,
        "repliesCount": 123,
        "replies": [DiscussionCommentData]
      }
    ]
  }
}
Queries

discussions

Response

Returns [DiscussionInfo!]!

Arguments
Name Description
args - IptObjectDiscussionsArg!
sort - IptSort
paginate - IptPaginate

Example

Query
query discussions(
  $args: IptObjectDiscussionsArg!,
  $sort: IptSort,
  $paginate: IptPaginate
) {
  discussions(
    args: $args,
    sort: $sort,
    paginate: $paginate
  ) {
    uuid
    title
    isPinned
    lastActivityAt
    createdAt
    repliesCount
    comments {
      ...DiscussionCommentDataFragment
    }
  }
}
Variables
{
  "args": IptObjectDiscussionsArg,
  "sort": IptSort,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "discussions": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "title": "abc123",
        "isPinned": false,
        "lastActivityAt": NaiveDateTime,
        "createdAt": NaiveDateTime,
        "repliesCount": 123,
        "comments": [DiscussionCommentData]
      }
    ]
  }
}
Queries

getCompaniesListAccessComponent

Response

Returns [CompanyAccessComponentAndRelatedData!]!

Arguments
Name Description
componentUuid - UUID!

Example

Query
query getCompaniesListAccessComponent($componentUuid: UUID!) {
  getCompaniesListAccessComponent(componentUuid: $componentUuid) {
    componentUuid
    company {
      ...ShowCompanyShortFragment
    }
    permission {
      ...PermissionTranslateListFragment
    }
    isEnabled
    createdAt
    updatedAt
  }
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "getCompaniesListAccessComponent": [
      {
        "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "company": ShowCompanyShort,
        "permission": PermissionTranslateList,
        "isEnabled": false,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

getCompaniesListAccessService

Response

Returns [CompanyAccessServiceAndRelatedData!]!

Arguments
Name Description
serviceUuid - UUID!

Example

Query
query getCompaniesListAccessService($serviceUuid: UUID!) {
  getCompaniesListAccessService(serviceUuid: $serviceUuid) {
    serviceUuid
    company {
      ...ShowCompanyShortFragment
    }
    permission {
      ...PermissionTranslateListFragment
    }
    isEnabled
    createdAt
    updatedAt
  }
}
Variables
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "getCompaniesListAccessService": [
      {
        "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "company": ShowCompanyShort,
        "permission": PermissionTranslateList,
        "isEnabled": true,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

getCompaniesListAccessStandard

Response

Returns [CompanyAccessStandardAndRelatedData!]!

Arguments
Name Description
standardUuid - UUID!

Example

Query
query getCompaniesListAccessStandard($standardUuid: UUID!) {
  getCompaniesListAccessStandard(standardUuid: $standardUuid) {
    standardUuid
    company {
      ...ShowCompanyShortFragment
    }
    permission {
      ...PermissionTranslateListFragment
    }
    isEnabled
    createdAt
    updatedAt
  }
}
Variables
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "getCompaniesListAccessStandard": [
      {
        "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "company": ShowCompanyShort,
        "permission": PermissionTranslateList,
        "isEnabled": false,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

getUsersListAccessComponent

Response

Returns [UserAccessComponentAndRelatedData!]!

Arguments
Name Description
componentUuid - UUID!

Example

Query
query getUsersListAccessComponent($componentUuid: UUID!) {
  getUsersListAccessComponent(componentUuid: $componentUuid) {
    componentUuid
    user {
      ...ShowUserShortFragment
    }
    permission {
      ...PermissionTranslateListFragment
    }
    isEnabled
    createdAt
    updatedAt
  }
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "getUsersListAccessComponent": [
      {
        "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "user": ShowUserShort,
        "permission": PermissionTranslateList,
        "isEnabled": false,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

getUsersListAccessService

Response

Returns [UserAccessServiceAndRelatedData!]!

Arguments
Name Description
serviceUuid - UUID!

Example

Query
query getUsersListAccessService($serviceUuid: UUID!) {
  getUsersListAccessService(serviceUuid: $serviceUuid) {
    serviceUuid
    user {
      ...ShowUserShortFragment
    }
    permission {
      ...PermissionTranslateListFragment
    }
    isEnabled
    createdAt
    updatedAt
  }
}
Variables
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "getUsersListAccessService": [
      {
        "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "user": ShowUserShort,
        "permission": PermissionTranslateList,
        "isEnabled": false,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

getUsersListAccessStandard

Response

Returns [UserAccessStandardAndRelatedData!]!

Arguments
Name Description
standardUuid - UUID!

Example

Query
query getUsersListAccessStandard($standardUuid: UUID!) {
  getUsersListAccessStandard(standardUuid: $standardUuid) {
    standardUuid
    user {
      ...ShowUserShortFragment
    }
    permission {
      ...PermissionTranslateListFragment
    }
    isEnabled
    createdAt
    updatedAt
  }
}
Variables
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "getUsersListAccessStandard": [
      {
        "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "user": ShowUserShort,
        "permission": PermissionTranslateList,
        "isEnabled": false,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

isTokenValid

Response

Returns a Boolean!

Example

Query
query isTokenValid {
  isTokenValid
}
Response
{"data": {"isTokenValid": false}}
Queries

keywords

Response

Returns [Keyword!]!

Arguments
Name Description
keywordIds - [Int!]!
paginate - IptPaginate

Example

Query
query keywords(
  $keywordIds: [Int!]!,
  $paginate: IptPaginate
) {
  keywords(
    keywordIds: $keywordIds,
    paginate: $paginate
  ) {
    id
    keyword
  }
}
Variables
{"keywordIds": [987], "paginate": IptPaginate}
Response
{
  "data": {
    "keywords": [
      {"id": 987, "keyword": "xyz789"}
    ]
  }
}
Queries

languages

Response

Returns [Language!]!

Arguments
Name Description
langIds - [Int!]
paginate - IptPaginate

Example

Query
query languages(
  $langIds: [Int!],
  $paginate: IptPaginate
) {
  languages(
    langIds: $langIds,
    paginate: $paginate
  ) {
    id
    lang
    langshort
  }
}
Variables
{"langIds": [987], "paginate": IptPaginate}
Response
{
  "data": {
    "languages": [
      {
        "id": 987,
        "lang": "xyz789",
        "langshort": "abc123"
      }
    ]
  }
}
Queries

licenses

Response

Returns [License!]!

Arguments
Name Description
licenseIds - [Int!]
paginate - IptPaginate

Example

Query
query licenses(
  $licenseIds: [Int!],
  $paginate: IptPaginate
) {
  licenses(
    licenseIds: $licenseIds,
    paginate: $paginate
  ) {
    id
    name
    keyword
    publicationAt
  }
}
Variables
{"licenseIds": [123], "paginate": IptPaginate}
Response
{
  "data": {
    "licenses": [
      {
        "id": 987,
        "name": "xyz789",
        "keyword": "xyz789",
        "publicationAt": NaiveDateTime
      }
    ]
  }
}
Queries

myAccessToCompany

Response

Returns an AccessCheckResult!

Arguments
Name Description
companyUuid - UUID!

Example

Query
query myAccessToCompany($companyUuid: UUID!) {
  myAccessToCompany(companyUuid: $companyUuid) {
    hasAccess
    accessLevel
    source
  }
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "myAccessToCompany": {
      "hasAccess": false,
      "accessLevel": 123,
      "source": "OWNER"
    }
  }
}
Queries

myAccessToComponent

Response

Returns an AccessCheckResult!

Arguments
Name Description
componentUuid - UUID!

Example

Query
query myAccessToComponent($componentUuid: UUID!) {
  myAccessToComponent(componentUuid: $componentUuid) {
    hasAccess
    accessLevel
    source
  }
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "myAccessToComponent": {
      "hasAccess": false,
      "accessLevel": 123,
      "source": "OWNER"
    }
  }
}
Queries

myAccessToService

Response

Returns an AccessCheckResult!

Arguments
Name Description
serviceUuid - UUID!

Example

Query
query myAccessToService($serviceUuid: UUID!) {
  myAccessToService(serviceUuid: $serviceUuid) {
    hasAccess
    accessLevel
    source
  }
}
Variables
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "myAccessToService": {
      "hasAccess": false,
      "accessLevel": 123,
      "source": "OWNER"
    }
  }
}
Queries

myAccessToStandard

Response

Returns an AccessCheckResult!

Arguments
Name Description
standardUuid - UUID!

Example

Query
query myAccessToStandard($standardUuid: UUID!) {
  myAccessToStandard(standardUuid: $standardUuid) {
    hasAccess
    accessLevel
    source
  }
}
Variables
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "myAccessToStandard": {
      "hasAccess": true,
      "accessLevel": 123,
      "source": "OWNER"
    }
  }
}
Queries

myself

Response

Returns a SlimUser!

Example

Query
query myself {
  myself {
    uuid
    username
    programId
  }
}
Response
{
  "data": {
    "myself": {
      "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "username": "xyz789",
      "programId": 987
    }
  }
}
Queries

notifications

Response

Returns [ShowNotification!]!

Arguments
Name Description
notificationIds - [Int!]
paginate - IptPaginate

Example

Query
query notifications(
  $notificationIds: [Int!],
  $paginate: IptPaginate
) {
  notifications(
    notificationIds: $notificationIds,
    paginate: $paginate
  ) {
    id
    notification
    degreeImportance {
      ...DegreeImportanceTranslateListFragment
    }
    createdAt
    isRead
  }
}
Variables
{"notificationIds": [123], "paginate": IptPaginate}
Response
{
  "data": {
    "notifications": [
      {
        "id": 987,
        "notification": "abc123",
        "degreeImportance": DegreeImportanceTranslateList,
        "createdAt": NaiveDateTime,
        "isRead": true
      }
    ]
  }
}
Queries

params

Response

Returns [ParamTranslateList!]!

Arguments
Name Description
paramIds - [Int!]
paginate - IptPaginate

Example

Query
query params(
  $paramIds: [Int!],
  $paginate: IptPaginate
) {
  params(
    paramIds: $paramIds,
    paginate: $paginate
  ) {
    paramId
    langId
    paramname
  }
}
Variables
{"paramIds": [123], "paginate": IptPaginate}
Response
{
  "data": {
    "params": [
      {
        "paramId": 123,
        "langId": 987,
        "paramname": "xyz789"
      }
    ]
  }
}
Queries

permissions

Response

Returns [PermissionTranslateList!]!

Arguments
Name Description
permissionIds - [Int!]
paginate - IptPaginate

Example

Query
query permissions(
  $permissionIds: [Int!],
  $paginate: IptPaginate
) {
  permissions(
    permissionIds: $permissionIds,
    paginate: $paginate
  ) {
    typeAccessId
    langId
    name
  }
}
Variables
{"permissionIds": [123], "paginate": IptPaginate}
Response
{
  "data": {
    "permissions": [
      {
        "typeAccessId": 987,
        "langId": 987,
        "name": "abc123"
      }
    ]
  }
}
Queries

presignedUrl

Response

Returns a DownloadFile!

Arguments
Name Description
fileUuid - UUID!

Example

Query
query presignedUrl($fileUuid: UUID!) {
  presignedUrl(fileUuid: $fileUuid) {
    uuid
    hash
    sha256Hash
    filename
    filesize
    downloadUrl
  }
}
Variables
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "presignedUrl": {
      "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "hash": "xyz789",
      "sha256Hash": "abc123",
      "filename": "abc123",
      "filesize": 987,
      "downloadUrl": "abc123"
    }
  }
}
Queries

programs

Response

Returns [Program!]!

Arguments
Name Description
programIds - [Int!]
paginate - IptPaginate

Example

Query
query programs(
  $programIds: [Int!],
  $paginate: IptPaginate
) {
  programs(
    programIds: $programIds,
    paginate: $paginate
  ) {
    id
    name
  }
}
Variables
{"programIds": [123], "paginate": IptPaginate}
Response
{
  "data": {
    "programs": [
      {"id": 987, "name": "xyz789"}
    ]
  }
}
Queries

regions

Response

Returns [RegionTranslateList!]!

Arguments
Name Description
regionIds - [Int!]
paginate - IptPaginate

Example

Query
query regions(
  $regionIds: [Int!],
  $paginate: IptPaginate
) {
  regions(
    regionIds: $regionIds,
    paginate: $paginate
  ) {
    regionId
    langId
    region
  }
}
Variables
{"regionIds": [123], "paginate": IptPaginate}
Response
{
  "data": {
    "regions": [
      {
        "regionId": 987,
        "langId": 123,
        "region": "xyz789"
      }
    ]
  }
}
Queries

searchByComponents

Response

Returns [ShowComponentShort!]!

Arguments
Name Description
args - IptSearchArg!
sort - IptSort
paginate - IptPaginate

Example

Query
query searchByComponents(
  $args: IptSearchArg!,
  $sort: IptSort,
  $paginate: IptPaginate
) {
  searchByComponents(
    args: $args,
    sort: $sort,
    paginate: $paginate
  ) {
    uuid
    name
    description
    imageFile {
      ...DownloadFileFragment
    }
    ownerUser {
      ...ShowUserShortFragment
    }
    typeAccess {
      ...TypeAccessTranslateListFragment
    }
    componentType {
      ...ComponentTypeTranslateListFragment
    }
    actualStatus {
      ...ActualStatusTranslateListFragment
    }
    isBase
    isFollowed
    createdAt
    updatedAt
    licenses {
      ...LicenseFragment
    }
    files {
      ...DownloadFileFragment
    }
    componentSuppliers {
      ...ComponentSupplierRelatedDataFragment
    }
  }
}
Variables
{
  "args": IptSearchArg,
  "sort": IptSort,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "searchByComponents": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "name": "xyz789",
        "description": "abc123",
        "imageFile": DownloadFile,
        "ownerUser": ShowUserShort,
        "typeAccess": TypeAccessTranslateList,
        "componentType": ComponentTypeTranslateList,
        "actualStatus": ActualStatusTranslateList,
        "isBase": false,
        "isFollowed": false,
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime,
        "licenses": [License],
        "files": [DownloadFile],
        "componentSuppliers": [
          ComponentSupplierRelatedData
        ]
      }
    ]
  }
}
Queries

searchSpecs

Response

Returns [SpecPath!]!

Arguments
Name Description
args - IptSearchSpecArg!
paginate - IptPaginate

Example

Query
query searchSpecs(
  $args: IptSearchSpecArg!,
  $paginate: IptPaginate
) {
  searchSpecs(
    args: $args,
    paginate: $paginate
  ) {
    specId
    langId
    path
    depth
  }
}
Variables
{
  "args": IptSearchSpecArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "searchSpecs": [
      {
        "specId": 987,
        "langId": 987,
        "path": "xyz789",
        "depth": 987
      }
    ]
  }
}
Queries

selfData

Response

Returns a UserAndRelatedData!

Example

Query
query selfData {
  selfData {
    uuid
    email
    firstname
    lastname
    secondname
    username
    phone
    description
    address
    position
    timeZone
    imageFile {
      ...DownloadFileFragment
    }
    region {
      ...RegionTranslateListFragment
    }
    program {
      ...ProgramFragment
    }
    typeAccess {
      ...TypeAccessTranslateListFragment
    }
    isEmailVerified
    createdAt
    updatedAt
    certificates {
      ...UserCertificateAndFileFragment
    }
    subscribers
    companiesCount
    componentsCount
    standardsCount
    favCompaniesCount
    favComponentsCount
    favStandardsCount
    favUsersCount
  }
}
Response
{
  "data": {
    "selfData": {
      "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "email": "xyz789",
      "firstname": "xyz789",
      "lastname": "xyz789",
      "secondname": "xyz789",
      "username": "xyz789",
      "phone": "xyz789",
      "description": "abc123",
      "address": "xyz789",
      "position": "abc123",
      "timeZone": "xyz789",
      "imageFile": DownloadFile,
      "region": RegionTranslateList,
      "program": Program,
      "typeAccess": TypeAccessTranslateList,
      "isEmailVerified": true,
      "createdAt": NaiveDateTime,
      "updatedAt": NaiveDateTime,
      "certificates": [UserCertificateAndFile],
      "subscribers": 987,
      "companiesCount": 123,
      "componentsCount": 987,
      "standardsCount": 123,
      "favCompaniesCount": 987,
      "favComponentsCount": 987,
      "favStandardsCount": 987,
      "favUsersCount": 987
    }
  }
}
Queries

service

Response

Returns a ServiceAndRelatedData!

Arguments
Name Description
serviceUuid - UUID!

Example

Query
query service($serviceUuid: UUID!) {
  service(serviceUuid: $serviceUuid) {
    uuid
    name
    description
    ownerUser {
      ...ShowUserShortFragment
    }
    ownerCompany {
      ...ShowCompanyShortFragment
    }
    serviceStatus {
      ...ServiceStatusTranslateListFragment
    }
    region {
      ...RegionTranslateListFragment
    }
    createdAt
    updatedAt
    serviceParams {
      ...ServiceParamWithTranslationFragment
    }
    paramsCount
    files {
      ...ShowFileRelatedDataFragment
    }
    filesCount
    serviceSpecs {
      ...SpecTranslateListFragment
    }
    serviceKeywords {
      ...KeywordFragment
    }
  }
}
Variables
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "service": {
      "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "name": "xyz789",
      "description": "xyz789",
      "ownerUser": ShowUserShort,
      "ownerCompany": ShowCompanyShort,
      "serviceStatus": ServiceStatusTranslateList,
      "region": RegionTranslateList,
      "createdAt": NaiveDateTime,
      "updatedAt": NaiveDateTime,
      "serviceParams": [ServiceParamWithTranslation],
      "paramsCount": 987,
      "files": [ShowFileRelatedData],
      "filesCount": 987,
      "serviceSpecs": [SpecTranslateList],
      "serviceKeywords": [Keyword]
    }
  }
}
Queries

serviceFiles

Response

Returns [DownloadFile!]!

Arguments
Name Description
args - IptServiceFilesArg!
paginate - IptPaginate

Example

Query
query serviceFiles(
  $args: IptServiceFilesArg!,
  $paginate: IptPaginate
) {
  serviceFiles(
    args: $args,
    paginate: $paginate
  ) {
    uuid
    hash
    sha256Hash
    filename
    filesize
    downloadUrl
  }
}
Variables
{
  "args": IptServiceFilesArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "serviceFiles": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "hash": "abc123",
        "sha256Hash": "abc123",
        "filename": "xyz789",
        "filesize": 987,
        "downloadUrl": "abc123"
      }
    ]
  }
}
Queries

serviceKeywords

Response

Returns [Keyword!]!

Arguments
Name Description
serviceUuid - UUID!
paginate - IptPaginate

Example

Query
query serviceKeywords(
  $serviceUuid: UUID!,
  $paginate: IptPaginate
) {
  serviceKeywords(
    serviceUuid: $serviceUuid,
    paginate: $paginate
  ) {
    id
    keyword
  }
}
Variables
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paginate": IptPaginate
}
Response
{
  "data": {
    "serviceKeywords": [
      {"id": 987, "keyword": "xyz789"}
    ]
  }
}
Queries

serviceSpecs

Response

Returns [SpecTranslateList!]!

Arguments
Name Description
serviceUuid - UUID!
paginate - IptPaginate

Example

Query
query serviceSpecs(
  $serviceUuid: UUID!,
  $paginate: IptPaginate
) {
  serviceSpecs(
    serviceUuid: $serviceUuid,
    paginate: $paginate
  ) {
    specId
    langId
    spec
    parentSpec {
      ...SpecTranslateListFragment
    }
  }
}
Variables
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paginate": IptPaginate
}
Response
{
  "data": {
    "serviceSpecs": [
      {
        "specId": 123,
        "langId": 123,
        "spec": "xyz789",
        "parentSpec": SpecTranslateList
      }
    ]
  }
}
Queries

serviceStatuses

Response

Returns [ServiceStatusTranslateList!]!

Arguments
Name Description
filter - [Int!]

Example

Query
query serviceStatuses($filter: [Int!]) {
  serviceStatuses(filter: $filter) {
    serviceStatusId
    langId
    name
  }
}
Variables
{"filter": [123]}
Response
{
  "data": {
    "serviceStatuses": [
      {
        "serviceStatusId": 987,
        "langId": 123,
        "name": "xyz789"
      }
    ]
  }
}
Queries

services

Response

Returns [ShowServiceShort!]!

Arguments
Name Description
args - IptServicesArg
sort - IptSort
paginate - IptPaginate

Example

Query
query services(
  $args: IptServicesArg,
  $sort: IptSort,
  $paginate: IptPaginate
) {
  services(
    args: $args,
    sort: $sort,
    paginate: $paginate
  ) {
    uuid
    name
    description
    ownerUser {
      ...ShowUserShortFragment
    }
    ownerCompany {
      ...ShowCompanyShortFragment
    }
    serviceStatus {
      ...ServiceStatusTranslateListFragment
    }
    updatedAt
    files {
      ...DownloadFileFragment
    }
  }
}
Variables
{
  "args": IptServicesArg,
  "sort": IptSort,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "services": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "name": "xyz789",
        "description": "xyz789",
        "ownerUser": ShowUserShort,
        "ownerCompany": ShowCompanyShort,
        "serviceStatus": ServiceStatusTranslateList,
        "updatedAt": NaiveDateTime,
        "files": [DownloadFile]
      }
    ]
  }
}
Queries

showFileRevisions

Response

Returns [ShowFileRelatedData!]!

Arguments
Name Description
fileUuid - UUID!
paginate - IptPaginate

Example

Query
query showFileRevisions(
  $fileUuid: UUID!,
  $paginate: IptPaginate
) {
  showFileRevisions(
    fileUuid: $fileUuid,
    paginate: $paginate
  ) {
    uuid
    filename
    revision
    commitMsg
    parentFileUuid
    ownerUser {
      ...ShowUserShortFragment
    }
    contentType
    filesize
    program {
      ...ProgramFragment
    }
    hash
    sha256Hash
    downloadUrl
    createdAt
    updatedAt
  }
}
Variables
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paginate": IptPaginate
}
Response
{
  "data": {
    "showFileRevisions": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "filename": "abc123",
        "revision": 123,
        "commitMsg": "abc123",
        "parentFileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "ownerUser": ShowUserShort,
        "contentType": "abc123",
        "filesize": 987,
        "program": Program,
        "hash": "xyz789",
        "sha256Hash": "abc123",
        "downloadUrl": "abc123",
        "createdAt": NaiveDateTime,
        "updatedAt": NaiveDateTime
      }
    ]
  }
}
Queries

showTokens

Response

Returns [UserToken!]!

Example

Query
query showTokens {
  showTokens {
    userUuid
    token
    createdAt
    expirationAt
  }
}
Response
{
  "data": {
    "showTokens": [
      {
        "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "token": "abc123",
        "createdAt": NaiveDateTime,
        "expirationAt": NaiveDateTime
      }
    ]
  }
}
Queries

specs

Response

Returns [SpecTranslateList!]!

Arguments
Name Description
args - IptSpecArg
paginate - IptPaginate

Example

Query
query specs(
  $args: IptSpecArg,
  $paginate: IptPaginate
) {
  specs(
    args: $args,
    paginate: $paginate
  ) {
    specId
    langId
    spec
    parentSpec {
      ...SpecTranslateListFragment
    }
  }
}
Variables
{
  "args": IptSpecArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "specs": [
      {
        "specId": 987,
        "langId": 987,
        "spec": "abc123",
        "parentSpec": SpecTranslateList
      }
    ]
  }
}
Queries

specsPaths

Response

Returns [SpecPath!]!

Arguments
Name Description
args - IptSpecPathArg
paginate - IptPaginate

Example

Query
query specsPaths(
  $args: IptSpecPathArg,
  $paginate: IptPaginate
) {
  specsPaths(
    args: $args,
    paginate: $paginate
  ) {
    specId
    langId
    path
    depth
  }
}
Variables
{
  "args": IptSpecPathArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "specsPaths": [
      {
        "specId": 987,
        "langId": 987,
        "path": "abc123",
        "depth": 987
      }
    ]
  }
}
Queries

standard

Response

Returns a StandardAndRelatedData!

Arguments
Name Description
standardUuid - UUID!
paginate - IptPaginate

Example

Query
query standard(
  $standardUuid: UUID!,
  $paginate: IptPaginate
) {
  standard(
    standardUuid: $standardUuid,
    paginate: $paginate
  ) {
    uuid
    parentStandardUuid
    name
    description
    publicationAt
    imageFile {
      ...DownloadFileFragment
    }
    ownerUser {
      ...ShowUserShortFragment
    }
    ownerCompany {
      ...ShowCompanyShortFragment
    }
    typeAccess {
      ...TypeAccessTranslateListFragment
    }
    standardStatus {
      ...StandardStatusTranslateListFragment
    }
    createdAt
    updatedAt
    standardFiles {
      ...ShowFileRelatedDataFragment
    }
    standardSpecs {
      ...SpecTranslateListFragment
    }
    standardKeywords {
      ...KeywordFragment
    }
    subscribers
    isFollowed
  }
}
Variables
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paginate": IptPaginate
}
Response
{
  "data": {
    "standard": {
      "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "parentStandardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "name": "xyz789",
      "description": "xyz789",
      "publicationAt": NaiveDateTime,
      "imageFile": DownloadFile,
      "ownerUser": ShowUserShort,
      "ownerCompany": ShowCompanyShort,
      "typeAccess": TypeAccessTranslateList,
      "standardStatus": StandardStatusTranslateList,
      "createdAt": NaiveDateTime,
      "updatedAt": NaiveDateTime,
      "standardFiles": [ShowFileRelatedData],
      "standardSpecs": [SpecTranslateList],
      "standardKeywords": [Keyword],
      "subscribers": 123,
      "isFollowed": true
    }
  }
}
Queries

standardFiles

Response

Returns [DownloadFile!]!

Arguments
Name Description
args - IptStandardFilesArg!
paginate - IptPaginate

Example

Query
query standardFiles(
  $args: IptStandardFilesArg!,
  $paginate: IptPaginate
) {
  standardFiles(
    args: $args,
    paginate: $paginate
  ) {
    uuid
    hash
    sha256Hash
    filename
    filesize
    downloadUrl
  }
}
Variables
{
  "args": IptStandardFilesArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "standardFiles": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "hash": "xyz789",
        "sha256Hash": "abc123",
        "filename": "abc123",
        "filesize": 987,
        "downloadUrl": "abc123"
      }
    ]
  }
}
Queries

standardKeywords

Response

Returns [Keyword!]!

Arguments
Name Description
standardUuid - UUID!
paginate - IptPaginate

Example

Query
query standardKeywords(
  $standardUuid: UUID!,
  $paginate: IptPaginate
) {
  standardKeywords(
    standardUuid: $standardUuid,
    paginate: $paginate
  ) {
    id
    keyword
  }
}
Variables
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paginate": IptPaginate
}
Response
{
  "data": {
    "standardKeywords": [
      {"id": 123, "keyword": "xyz789"}
    ]
  }
}
Queries

standardSpecs

Response

Returns [SpecTranslateList!]!

Arguments
Name Description
standardUuid - UUID!
paginate - IptPaginate

Example

Query
query standardSpecs(
  $standardUuid: UUID!,
  $paginate: IptPaginate
) {
  standardSpecs(
    standardUuid: $standardUuid,
    paginate: $paginate
  ) {
    specId
    langId
    spec
    parentSpec {
      ...SpecTranslateListFragment
    }
  }
}
Variables
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paginate": IptPaginate
}
Response
{
  "data": {
    "standardSpecs": [
      {
        "specId": 987,
        "langId": 987,
        "spec": "abc123",
        "parentSpec": SpecTranslateList
      }
    ]
  }
}
Queries

standardStatuses

Response

Returns [StandardStatusTranslateList!]!

Arguments
Name Description
filter - [Int!]

Example

Query
query standardStatuses($filter: [Int!]) {
  standardStatuses(filter: $filter) {
    standardStatusId
    langId
    name
  }
}
Variables
{"filter": [123]}
Response
{
  "data": {
    "standardStatuses": [
      {
        "standardStatusId": 987,
        "langId": 123,
        "name": "abc123"
      }
    ]
  }
}
Queries

standards

Response

Returns [ShowStandardShort!]!

Arguments
Name Description
args - IptStandardsArg
paginate - IptPaginate

Example

Query
query standards(
  $args: IptStandardsArg,
  $paginate: IptPaginate
) {
  standards(
    args: $args,
    paginate: $paginate
  ) {
    uuid
    name
    description
    publicationAt
    imageFile {
      ...DownloadFileFragment
    }
    ownerCompany {
      ...ShowCompanyShortFragment
    }
    standardStatus {
      ...StandardStatusTranslateListFragment
    }
    updatedAt
    isFollowed
  }
}
Variables
{
  "args": IptStandardsArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "standards": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "name": "xyz789",
        "description": "abc123",
        "publicationAt": NaiveDateTime,
        "imageFile": DownloadFile,
        "ownerCompany": ShowCompanyShort,
        "standardStatus": StandardStatusTranslateList,
        "updatedAt": NaiveDateTime,
        "isFollowed": true
      }
    ]
  }
}
Queries

supplierCompany

Response

Returns a CompanyAndRelatedData!

Arguments
Name Description
companyUuid - UUID!

Example

Query
query supplierCompany($companyUuid: UUID!) {
  supplierCompany(companyUuid: $companyUuid) {
    uuid
    orgname
    shortname
    inn
    phone
    email
    description
    address
    siteUrl
    timeZone
    ownerUser {
      ...ShowUserShortFragment
    }
    imageFile {
      ...DownloadFileFragment
    }
    region {
      ...RegionTranslateListFragment
    }
    companyRepresents {
      ...CompanyRepresentAndRelatedDataFragment
    }
    companyType {
      ...CompanyTypeTranslateListFragment
    }
    companyCertificates {
      ...CompanyCertificateAndFileFragment
    }
    companySpecs {
      ...SpecTranslateListFragment
    }
    typeAccess {
      ...TypeAccessTranslateListFragment
    }
    isSupplier
    isEmailVerified
    subscribers
    isFollowed
    createdAt
    updatedAt
  }
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "supplierCompany": {
      "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "orgname": "xyz789",
      "shortname": "xyz789",
      "inn": "xyz789",
      "phone": "abc123",
      "email": "xyz789",
      "description": "abc123",
      "address": "xyz789",
      "siteUrl": "xyz789",
      "timeZone": "abc123",
      "ownerUser": ShowUserShort,
      "imageFile": DownloadFile,
      "region": RegionTranslateList,
      "companyRepresents": [
        CompanyRepresentAndRelatedData
      ],
      "companyType": CompanyTypeTranslateList,
      "companyCertificates": [CompanyCertificateAndFile],
      "companySpecs": [SpecTranslateList],
      "typeAccess": TypeAccessTranslateList,
      "isSupplier": true,
      "isEmailVerified": false,
      "subscribers": 987,
      "isFollowed": false,
      "createdAt": NaiveDateTime,
      "updatedAt": NaiveDateTime
    }
  }
}
Queries

tokenDaysUntilExpiry

Response

Returns an Int!

Example

Query
query tokenDaysUntilExpiry {
  tokenDaysUntilExpiry
}
Response
{"data": {"tokenDaysUntilExpiry": 123}}
Queries

typesAccess

Response

Returns [TypeAccessTranslateList!]!

Arguments
Name Description
typeAccessIds - [Int!]
paginate - IptPaginate

Example

Query
query typesAccess(
  $typeAccessIds: [Int!],
  $paginate: IptPaginate
) {
  typesAccess(
    typeAccessIds: $typeAccessIds,
    paginate: $paginate
  ) {
    typeAccessId
    langId
    name
  }
}
Variables
{"typeAccessIds": [123], "paginate": IptPaginate}
Response
{
  "data": {
    "typesAccess": [
      {
        "typeAccessId": 987,
        "langId": 987,
        "name": "abc123"
      }
    ]
  }
}
Queries

user

Response

Returns a ShowUserAndRelatedData!

Arguments
Name Description
args - IptGetUserArg!

Example

Query
query user($args: IptGetUserArg!) {
  user(args: $args) {
    uuid
    firstname
    lastname
    secondname
    username
    description
    position
    imageFile {
      ...DownloadFileFragment
    }
    region {
      ...RegionTranslateListFragment
    }
    program {
      ...ProgramFragment
    }
    createdAt
    updatedAt
    certificates {
      ...UserCertificateAndFileFragment
    }
    subscribers
    isFollowed
  }
}
Variables
{"args": IptGetUserArg}
Response
{
  "data": {
    "user": {
      "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "firstname": "xyz789",
      "lastname": "xyz789",
      "secondname": "abc123",
      "username": "xyz789",
      "description": "xyz789",
      "position": "xyz789",
      "imageFile": DownloadFile,
      "region": RegionTranslateList,
      "program": Program,
      "createdAt": NaiveDateTime,
      "updatedAt": NaiveDateTime,
      "certificates": [UserCertificateAndFile],
      "subscribers": 987,
      "isFollowed": true
    }
  }
}
Queries

users

Response

Returns [ShowUserShort!]!

Arguments
Name Description
args - IptUsersArg
paginate - IptPaginate

Example

Query
query users(
  $args: IptUsersArg,
  $paginate: IptPaginate
) {
  users(
    args: $args,
    paginate: $paginate
  ) {
    uuid
    firstname
    lastname
    username
    imageFile {
      ...DownloadFileFragment
    }
  }
}
Variables
{
  "args": IptUsersArg,
  "paginate": IptPaginate
}
Response
{
  "data": {
    "users": [
      {
        "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "firstname": "abc123",
        "lastname": "abc123",
        "username": "xyz789",
        "imageFile": DownloadFile
      }
    ]
  }
}

Mutations

addAccessRole

Response

Returns an Int!

Arguments
Name Description
args - IptRoleAccessData!

Example

Query
mutation addAccessRole($args: IptRoleAccessData!) {
  addAccessRole(args: $args)
}
Variables
{"args": IptRoleAccessData}
Response
{"data": {"addAccessRole": 123}}
Mutations

addCompanyFav

Response

Returns a Boolean!

Arguments
Name Description
companyUuid - UUID!

Example

Query
mutation addCompanyFav($companyUuid: UUID!) {
  addCompanyFav(companyUuid: $companyUuid)
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"addCompanyFav": true}}
Mutations

addCompanyMember

Response

Returns a Boolean!

Arguments
Name Description
args - IptCompanyMemberData!

Example

Query
mutation addCompanyMember($args: IptCompanyMemberData!) {
  addCompanyMember(args: $args)
}
Variables
{"args": IptCompanyMemberData}
Response
{"data": {"addCompanyMember": false}}
Mutations

addCompanySpecs

Response

Returns an Int!

Arguments
Name Description
args - IptCompanySpecsData!

Example

Query
mutation addCompanySpecs($args: IptCompanySpecsData!) {
  addCompanySpecs(args: $args)
}
Variables
{"args": IptCompanySpecsData}
Response
{"data": {"addCompanySpecs": 987}}
Mutations

addComponentFav

Response

Returns a Boolean!

Arguments
Name Description
componentUuid - UUID!

Example

Query
mutation addComponentFav($componentUuid: UUID!) {
  addComponentFav(componentUuid: $componentUuid)
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"addComponentFav": false}}
Mutations

addComponentKeywords

Response

Returns an Int!

Arguments
Name Description
args - IptComponentKeywordsData!

Example

Query
mutation addComponentKeywords($args: IptComponentKeywordsData!) {
  addComponentKeywords(args: $args)
}
Variables
{"args": IptComponentKeywordsData}
Response
{"data": {"addComponentKeywords": 987}}
Mutations

addComponentKeywordsByNames

Response

Returns an Int!

Arguments
Name Description
args - IptComponentKeywordsNames!

Example

Query
mutation addComponentKeywordsByNames($args: IptComponentKeywordsNames!) {
  addComponentKeywordsByNames(args: $args)
}
Variables
{"args": IptComponentKeywordsNames}
Response
{"data": {"addComponentKeywordsByNames": 987}}
Mutations

addComponentLicense

Response

Returns a Boolean!

Arguments
Name Description
args - IptComponentLicenseData!

Example

Query
mutation addComponentLicense($args: IptComponentLicenseData!) {
  addComponentLicense(args: $args)
}
Variables
{"args": IptComponentLicenseData}
Response
{"data": {"addComponentLicense": true}}
Mutations

addComponentSpecs

Response

Returns an Int!

Arguments
Name Description
args - IptComponentSpecsData!

Example

Query
mutation addComponentSpecs($args: IptComponentSpecsData!) {
  addComponentSpecs(args: $args)
}
Variables
{"args": IptComponentSpecsData}
Response
{"data": {"addComponentSpecs": 123}}
Mutations

addComponentSupplier

Response

Returns a Boolean!

Arguments
Name Description
args - IptSupplierComponentData!

Example

Query
mutation addComponentSupplier($args: IptSupplierComponentData!) {
  addComponentSupplier(args: $args)
}
Variables
{"args": IptSupplierComponentData}
Response
{"data": {"addComponentSupplier": false}}
Mutations

addServiceKeywords

Response

Returns an Int!

Arguments
Name Description
args - IptServiceKeywordsData!

Example

Query
mutation addServiceKeywords($args: IptServiceKeywordsData!) {
  addServiceKeywords(args: $args)
}
Variables
{"args": IptServiceKeywordsData}
Response
{"data": {"addServiceKeywords": 123}}
Mutations

addServiceKeywordsByNames

Response

Returns an Int!

Arguments
Name Description
args - IptServiceKeywordsNames!

Example

Query
mutation addServiceKeywordsByNames($args: IptServiceKeywordsNames!) {
  addServiceKeywordsByNames(args: $args)
}
Variables
{"args": IptServiceKeywordsNames}
Response
{"data": {"addServiceKeywordsByNames": 123}}
Mutations

addServiceSpecs

Response

Returns an Int!

Arguments
Name Description
args - IptServiceSpecsData!

Example

Query
mutation addServiceSpecs($args: IptServiceSpecsData!) {
  addServiceSpecs(args: $args)
}
Variables
{"args": IptServiceSpecsData}
Response
{"data": {"addServiceSpecs": 123}}
Mutations

addStandardFav

Response

Returns a Boolean!

Arguments
Name Description
standardUuid - UUID!

Example

Query
mutation addStandardFav($standardUuid: UUID!) {
  addStandardFav(standardUuid: $standardUuid)
}
Variables
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"addStandardFav": false}}
Mutations

addStandardKeywords

Response

Returns an Int!

Arguments
Name Description
args - IptStandardKeywordsData!

Example

Query
mutation addStandardKeywords($args: IptStandardKeywordsData!) {
  addStandardKeywords(args: $args)
}
Variables
{"args": IptStandardKeywordsData}
Response
{"data": {"addStandardKeywords": 123}}
Mutations

addStandardKeywordsByNames

Response

Returns an Int!

Arguments
Name Description
args - IptStandardKeywordsNames!

Example

Query
mutation addStandardKeywordsByNames($args: IptStandardKeywordsNames!) {
  addStandardKeywordsByNames(args: $args)
}
Variables
{"args": IptStandardKeywordsNames}
Response
{"data": {"addStandardKeywordsByNames": 987}}
Mutations

addStandardSpecs

Response

Returns an Int!

Arguments
Name Description
args - IptStandardSpecsData!

Example

Query
mutation addStandardSpecs($args: IptStandardSpecsData!) {
  addStandardSpecs(args: $args)
}
Variables
{"args": IptStandardSpecsData}
Response
{"data": {"addStandardSpecs": 123}}
Mutations

addStandardToComponent

Response

Returns a Boolean!

Arguments
Name Description
args - IptStandardToComponentData!

Example

Query
mutation addStandardToComponent($args: IptStandardToComponentData!) {
  addStandardToComponent(args: $args)
}
Variables
{"args": IptStandardToComponentData}
Response
{"data": {"addStandardToComponent": true}}
Mutations

addUserFav

Response

Returns a Boolean!

Arguments
Name Description
userUuid - UUID!

Example

Query
mutation addUserFav($userUuid: UUID!) {
  addUserFav(userUuid: $userUuid)
}
Variables
{
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"addUserFav": false}}
Mutations

changeActiveFileRevision

Response

Returns a Boolean!

Arguments
Name Description
fileUuid - UUID!

Example

Query
mutation changeActiveFileRevision($fileUuid: UUID!) {
  changeActiveFileRevision(fileUuid: $fileUuid)
}
Variables
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"changeActiveFileRevision": true}}
Mutations

changeCompanyAccess

Response

Returns a Boolean!

Arguments
Name Description
args - ChangeTypeAccessCompany!

Example

Query
mutation changeCompanyAccess($args: ChangeTypeAccessCompany!) {
  changeCompanyAccess(args: $args)
}
Variables
{"args": ChangeTypeAccessCompany}
Response
{"data": {"changeCompanyAccess": true}}
Mutations

changeComponentAccess

Response

Returns a Boolean!

Arguments
Name Description
args - ChangeTypeAccessComponent!

Example

Query
mutation changeComponentAccess($args: ChangeTypeAccessComponent!) {
  changeComponentAccess(args: $args)
}
Variables
{"args": ChangeTypeAccessComponent}
Response
{"data": {"changeComponentAccess": false}}
Mutations

changeNameRoleCompany

Response

Returns a Boolean!

Arguments
Name Description
args - IptUpdateNameRoleData!

Example

Query
mutation changeNameRoleCompany($args: IptUpdateNameRoleData!) {
  changeNameRoleCompany(args: $args)
}
Variables
{"args": IptUpdateNameRoleData}
Response
{"data": {"changeNameRoleCompany": false}}
Mutations

changeRoleMember

Response

Returns a Boolean!

Arguments
Name Description
args - IptCompanyMemberData!

Example

Query
mutation changeRoleMember($args: IptCompanyMemberData!) {
  changeRoleMember(args: $args)
}
Variables
{"args": IptCompanyMemberData}
Response
{"data": {"changeRoleMember": false}}
Mutations

changeServiceAccess

Response

Returns a Boolean!

Arguments
Name Description
args - ChangeTypeAccessService!

Example

Query
mutation changeServiceAccess($args: ChangeTypeAccessService!) {
  changeServiceAccess(args: $args)
}
Variables
{"args": ChangeTypeAccessService}
Response
{"data": {"changeServiceAccess": false}}
Mutations

changeServiceStatus

Response

Returns a Boolean!

Arguments
Name Description
args - IptServiceStatusArg!

Example

Query
mutation changeServiceStatus($args: IptServiceStatusArg!) {
  changeServiceStatus(args: $args)
}
Variables
{"args": IptServiceStatusArg}
Response
{"data": {"changeServiceStatus": false}}
Mutations

changeStandardAccess

Response

Returns a Boolean!

Arguments
Name Description
args - ChangeTypeAccessStandard!

Example

Query
mutation changeStandardAccess($args: ChangeTypeAccessStandard!) {
  changeStandardAccess(args: $args)
}
Variables
{"args": ChangeTypeAccessStandard}
Response
{"data": {"changeStandardAccess": true}}
Mutations

changeTypeAccessUser

Response

Returns a Boolean!

Arguments
Name Description
newTypeAccess - Int!

Example

Query
mutation changeTypeAccessUser($newTypeAccess: Int!) {
  changeTypeAccessUser(newTypeAccess: $newTypeAccess)
}
Variables
{"newTypeAccess": 987}
Response
{"data": {"changeTypeAccessUser": false}}
Mutations

createApiKey

Response

Returns a String!

Arguments
Name Description
name - String!
expiresAt - DateTime

Example

Query
mutation createApiKey(
  $name: String!,
  $expiresAt: DateTime
) {
  createApiKey(
    name: $name,
    expiresAt: $expiresAt
  )
}
Variables
{
  "name": "abc123",
  "expiresAt": "2007-12-03T10:15:30Z"
}
Response
{"data": {"createApiKey": "abc123"}}
Mutations

deleteAccessRole

Response

Returns an Int!

Arguments
Name Description
args - DelRoleAccessData!

Example

Query
mutation deleteAccessRole($args: DelRoleAccessData!) {
  deleteAccessRole(args: $args)
}
Variables
{"args": DelRoleAccessData}
Response
{"data": {"deleteAccessRole": 123}}
Mutations

deleteAllTokens

Response

Returns an Int!

Example

Query
mutation deleteAllTokens {
  deleteAllTokens
}
Response
{"data": {"deleteAllTokens": 123}}
Mutations

deleteApiKey

Response

Returns a Boolean!

Arguments
Name Description
keyId - Int!

Example

Query
mutation deleteApiKey($keyId: Int!) {
  deleteApiKey(keyId: $keyId)
}
Variables
{"keyId": 123}
Response
{"data": {"deleteApiKey": false}}
Mutations

deleteComment

Response

Returns a Boolean!

Arguments
Name Description
commentUuid - UUID!

Example

Query
mutation deleteComment($commentUuid: UUID!) {
  deleteComment(commentUuid: $commentUuid)
}
Variables
{
  "commentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"deleteComment": false}}
Mutations

deleteCompany

Response

Returns a UUID!

Arguments
Name Description
companyUuid - UUID!

Example

Query
mutation deleteCompany($companyUuid: UUID!) {
  deleteCompany(companyUuid: $companyUuid)
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "deleteCompany": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

deleteCompanyAccessComponent

Response

Returns a Boolean!

Arguments
Name Description
args - DelCompanyAccessComponentData!

Example

Query
mutation deleteCompanyAccessComponent($args: DelCompanyAccessComponentData!) {
  deleteCompanyAccessComponent(args: $args)
}
Variables
{"args": DelCompanyAccessComponentData}
Response
{"data": {"deleteCompanyAccessComponent": true}}
Mutations

deleteCompanyAccessService

Response

Returns a Boolean!

Arguments
Name Description
args - DelCompanyAccessServiceData!

Example

Query
mutation deleteCompanyAccessService($args: DelCompanyAccessServiceData!) {
  deleteCompanyAccessService(args: $args)
}
Variables
{"args": DelCompanyAccessServiceData}
Response
{"data": {"deleteCompanyAccessService": false}}
Mutations

deleteCompanyAccessStandard

Response

Returns a Boolean!

Arguments
Name Description
args - DelCompanyAccessStandardData!

Example

Query
mutation deleteCompanyAccessStandard($args: DelCompanyAccessStandardData!) {
  deleteCompanyAccessStandard(args: $args)
}
Variables
{"args": DelCompanyAccessStandardData}
Response
{"data": {"deleteCompanyAccessStandard": true}}
Mutations

deleteCompanyCertificate

Response

Returns a Boolean!

Arguments
Name Description
args - DelCompanyCertificateData!

Example

Query
mutation deleteCompanyCertificate($args: DelCompanyCertificateData!) {
  deleteCompanyCertificate(args: $args)
}
Variables
{"args": DelCompanyCertificateData}
Response
{"data": {"deleteCompanyCertificate": false}}
Mutations

deleteCompanyFav

Response

Returns a Boolean!

Arguments
Name Description
companyUuid - UUID!

Example

Query
mutation deleteCompanyFav($companyUuid: UUID!) {
  deleteCompanyFav(companyUuid: $companyUuid)
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"deleteCompanyFav": false}}
Mutations

deleteCompanyMember

Response

Returns a Boolean!

Arguments
Name Description
args - DelCompanyMemberData!

Example

Query
mutation deleteCompanyMember($args: DelCompanyMemberData!) {
  deleteCompanyMember(args: $args)
}
Variables
{"args": DelCompanyMemberData}
Response
{"data": {"deleteCompanyMember": true}}
Mutations

deleteCompanyRepresent

Response

Returns a Boolean!

Arguments
Name Description
companyUuid - UUID!
companyRepresentUuid - UUID!

Example

Query
mutation deleteCompanyRepresent(
  $companyUuid: UUID!,
  $companyRepresentUuid: UUID!
) {
  deleteCompanyRepresent(
    companyUuid: $companyUuid,
    companyRepresentUuid: $companyRepresentUuid
  )
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companyRepresentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"deleteCompanyRepresent": true}}
Mutations

deleteCompanyRole

Response

Returns a Boolean!

Arguments
Name Description
args - DelRoleMemberData!

Example

Query
mutation deleteCompanyRole($args: DelRoleMemberData!) {
  deleteCompanyRole(args: $args)
}
Variables
{"args": DelRoleMemberData}
Response
{"data": {"deleteCompanyRole": true}}
Mutations

deleteCompanySpecs

Response

Returns an Int!

Arguments
Name Description
args - IptCompanySpecsData!

Example

Query
mutation deleteCompanySpecs($args: IptCompanySpecsData!) {
  deleteCompanySpecs(args: $args)
}
Variables
{"args": IptCompanySpecsData}
Response
{"data": {"deleteCompanySpecs": 123}}
Mutations

deleteComponent

Response

Returns a UUID!

Arguments
Name Description
componentUuid - UUID!

Example

Query
mutation deleteComponent($componentUuid: UUID!) {
  deleteComponent(componentUuid: $componentUuid)
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "deleteComponent": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

deleteComponentFav

Response

Returns a Boolean!

Arguments
Name Description
componentUuid - UUID!

Example

Query
mutation deleteComponentFav($componentUuid: UUID!) {
  deleteComponentFav(componentUuid: $componentUuid)
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"deleteComponentFav": true}}
Mutations

deleteComponentFile

Response

Returns a Boolean!

Arguments
Name Description
args - DelComponentFileData!

Example

Query
mutation deleteComponentFile($args: DelComponentFileData!) {
  deleteComponentFile(args: $args)
}
Variables
{"args": DelComponentFileData}
Response
{"data": {"deleteComponentFile": false}}
Mutations

deleteComponentKeywords

Response

Returns an Int!

Arguments
Name Description
args - IptComponentKeywordsData!

Example

Query
mutation deleteComponentKeywords($args: IptComponentKeywordsData!) {
  deleteComponentKeywords(args: $args)
}
Variables
{"args": IptComponentKeywordsData}
Response
{"data": {"deleteComponentKeywords": 123}}
Mutations

deleteComponentLicense

Response

Returns an Int!

Arguments
Name Description
args - IptComponentLicenseData!

Example

Query
mutation deleteComponentLicense($args: IptComponentLicenseData!) {
  deleteComponentLicense(args: $args)
}
Variables
{"args": IptComponentLicenseData}
Response
{"data": {"deleteComponentLicense": 987}}
Mutations

deleteComponentModification

Response

Returns a UUID!

Arguments
Name Description
args - DelComponentModificationData!

Example

Query
mutation deleteComponentModification($args: DelComponentModificationData!) {
  deleteComponentModification(args: $args)
}
Variables
{"args": DelComponentModificationData}
Response
{
  "data": {
    "deleteComponentModification": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

deleteComponentParams

Response

Returns an Int!

Arguments
Name Description
args - DelComponentParamData!

Example

Query
mutation deleteComponentParams($args: DelComponentParamData!) {
  deleteComponentParams(args: $args)
}
Variables
{"args": DelComponentParamData}
Response
{"data": {"deleteComponentParams": 123}}
Mutations

deleteComponentSpecs

Response

Returns an Int!

Arguments
Name Description
args - IptComponentSpecsData!

Example

Query
mutation deleteComponentSpecs($args: IptComponentSpecsData!) {
  deleteComponentSpecs(args: $args)
}
Variables
{"args": IptComponentSpecsData}
Response
{"data": {"deleteComponentSpecs": 987}}
Mutations

deleteFile

Response

Returns a Boolean!

Arguments
Name Description
fileUuid - UUID!

Example

Query
mutation deleteFile($fileUuid: UUID!) {
  deleteFile(fileUuid: $fileUuid)
}
Variables
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"deleteFile": false}}
Mutations

deleteFilesFromFileset

Response

Returns a Boolean!

Arguments
Name Description
args - DelModificationFileFromFilesetData!

Example

Query
mutation deleteFilesFromFileset($args: DelModificationFileFromFilesetData!) {
  deleteFilesFromFileset(args: $args)
}
Variables
{"args": DelModificationFileFromFilesetData}
Response
{"data": {"deleteFilesFromFileset": true}}
Mutations

deleteModificationFile

Response

Returns a Boolean!

Arguments
Name Description
args - DelModificationFileData!

Example

Query
mutation deleteModificationFile($args: DelModificationFileData!) {
  deleteModificationFile(args: $args)
}
Variables
{"args": DelModificationFileData}
Response
{"data": {"deleteModificationFile": true}}
Mutations

deleteModificationFileset

Response

Returns a Boolean!

Arguments
Name Description
args - DelFilesetProgramData!

Example

Query
mutation deleteModificationFileset($args: DelFilesetProgramData!) {
  deleteModificationFileset(args: $args)
}
Variables
{"args": DelFilesetProgramData}
Response
{"data": {"deleteModificationFileset": true}}
Mutations

deleteModificationParams

Response

Returns an Int!

Arguments
Name Description
args - DelModificationParamData!

Example

Query
mutation deleteModificationParams($args: DelModificationParamData!) {
  deleteModificationParams(args: $args)
}
Variables
{"args": DelModificationParamData}
Response
{"data": {"deleteModificationParams": 987}}
Mutations

deleteNotifications

Response

Returns an Int!

Arguments
Name Description
notificationsIds - [Int!]!

Example

Query
mutation deleteNotifications($notificationsIds: [Int!]!) {
  deleteNotifications(notificationsIds: $notificationsIds)
}
Variables
{"notificationsIds": [123]}
Response
{"data": {"deleteNotifications": 123}}
Mutations

deleteService

Response

Returns a UUID!

Arguments
Name Description
serviceUuid - UUID!

Example

Query
mutation deleteService($serviceUuid: UUID!) {
  deleteService(serviceUuid: $serviceUuid)
}
Variables
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "deleteService": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

deleteServiceFile

Response

Returns a Boolean!

Arguments
Name Description
args - DeleteServiceFileData!

Example

Query
mutation deleteServiceFile($args: DeleteServiceFileData!) {
  deleteServiceFile(args: $args)
}
Variables
{"args": DeleteServiceFileData}
Response
{"data": {"deleteServiceFile": false}}
Mutations

deleteServiceKeywords

Response

Returns an Int!

Arguments
Name Description
args - IptServiceKeywordsData!

Example

Query
mutation deleteServiceKeywords($args: IptServiceKeywordsData!) {
  deleteServiceKeywords(args: $args)
}
Variables
{"args": IptServiceKeywordsData}
Response
{"data": {"deleteServiceKeywords": 987}}
Mutations

deleteServiceParams

Response

Returns an Int!

Arguments
Name Description
args - DelServiceParamData!

Example

Query
mutation deleteServiceParams($args: DelServiceParamData!) {
  deleteServiceParams(args: $args)
}
Variables
{"args": DelServiceParamData}
Response
{"data": {"deleteServiceParams": 123}}
Mutations

deleteServiceSpecs

Response

Returns an Int!

Arguments
Name Description
args - IptServiceSpecsData!

Example

Query
mutation deleteServiceSpecs($args: IptServiceSpecsData!) {
  deleteServiceSpecs(args: $args)
}
Variables
{"args": IptServiceSpecsData}
Response
{"data": {"deleteServiceSpecs": 123}}
Mutations

deleteStandard

Response

Returns a UUID!

Arguments
Name Description
standardUuid - UUID!

Example

Query
mutation deleteStandard($standardUuid: UUID!) {
  deleteStandard(standardUuid: $standardUuid)
}
Variables
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{
  "data": {
    "deleteStandard": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

deleteStandardFav

Response

Returns a Boolean!

Arguments
Name Description
standardUuid - UUID!

Example

Query
mutation deleteStandardFav($standardUuid: UUID!) {
  deleteStandardFav(standardUuid: $standardUuid)
}
Variables
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"deleteStandardFav": true}}
Mutations

deleteStandardFile

Response

Returns a Boolean!

Arguments
Name Description
args - DeleteStandardFileData!

Example

Query
mutation deleteStandardFile($args: DeleteStandardFileData!) {
  deleteStandardFile(args: $args)
}
Variables
{"args": DeleteStandardFileData}
Response
{"data": {"deleteStandardFile": false}}
Mutations

deleteStandardKeywords

Response

Returns an Int!

Arguments
Name Description
args - IptStandardKeywordsData!

Example

Query
mutation deleteStandardKeywords($args: IptStandardKeywordsData!) {
  deleteStandardKeywords(args: $args)
}
Variables
{"args": IptStandardKeywordsData}
Response
{"data": {"deleteStandardKeywords": 987}}
Mutations

deleteStandardSpecs

Response

Returns an Int!

Arguments
Name Description
args - IptStandardSpecsData!

Example

Query
mutation deleteStandardSpecs($args: IptStandardSpecsData!) {
  deleteStandardSpecs(args: $args)
}
Variables
{"args": IptStandardSpecsData}
Response
{"data": {"deleteStandardSpecs": 987}}
Mutations

deleteStandardsComponent

Response

Returns an Int!

Arguments
Name Description
args - DelStandardToComponentData!

Example

Query
mutation deleteStandardsComponent($args: DelStandardToComponentData!) {
  deleteStandardsComponent(args: $args)
}
Variables
{"args": DelStandardToComponentData}
Response
{"data": {"deleteStandardsComponent": 987}}
Mutations

deleteSupplierCompany

Response

Returns a Boolean!

Arguments
Name Description
args - DelCompanyOfSuppliersData!

Example

Query
mutation deleteSupplierCompany($args: DelCompanyOfSuppliersData!) {
  deleteSupplierCompany(args: $args)
}
Variables
{"args": DelCompanyOfSuppliersData}
Response
{"data": {"deleteSupplierCompany": false}}
Mutations

deleteSuppliersComponent

Response

Returns an Int!

Arguments
Name Description
args - DelSuppliersComponentData!

Example

Query
mutation deleteSuppliersComponent($args: DelSuppliersComponentData!) {
  deleteSuppliersComponent(args: $args)
}
Variables
{"args": DelSuppliersComponentData}
Response
{"data": {"deleteSuppliersComponent": 987}}
Mutations

deleteToken

Response

Returns a Boolean!

Arguments
Name Description
token - String!

Example

Query
mutation deleteToken($token: String!) {
  deleteToken(token: $token)
}
Variables
{"token": "abc123"}
Response
{"data": {"deleteToken": false}}
Mutations

deleteUserAccessComponent

Response

Returns a Boolean!

Arguments
Name Description
args - DelUserAccessComponentData!

Example

Query
mutation deleteUserAccessComponent($args: DelUserAccessComponentData!) {
  deleteUserAccessComponent(args: $args)
}
Variables
{"args": DelUserAccessComponentData}
Response
{"data": {"deleteUserAccessComponent": false}}
Mutations

deleteUserAccessService

Response

Returns a Boolean!

Arguments
Name Description
args - DelUserAccessServiceData!

Example

Query
mutation deleteUserAccessService($args: DelUserAccessServiceData!) {
  deleteUserAccessService(args: $args)
}
Variables
{"args": DelUserAccessServiceData}
Response
{"data": {"deleteUserAccessService": true}}
Mutations

deleteUserAccessStandard

Response

Returns a Boolean!

Arguments
Name Description
args - DelUserAccessStandardData!

Example

Query
mutation deleteUserAccessStandard($args: DelUserAccessStandardData!) {
  deleteUserAccessStandard(args: $args)
}
Variables
{"args": DelUserAccessStandardData}
Response
{"data": {"deleteUserAccessStandard": false}}
Mutations

deleteUserCertificate

Response

Returns a Boolean!

Arguments
Name Description
args - DelUserCertificateData!

Example

Query
mutation deleteUserCertificate($args: DelUserCertificateData!) {
  deleteUserCertificate(args: $args)
}
Variables
{"args": DelUserCertificateData}
Response
{"data": {"deleteUserCertificate": true}}
Mutations

deleteUserData

Response

Returns a Boolean!

Arguments
Name Description
password - String!

Example

Query
mutation deleteUserData($password: String!) {
  deleteUserData(password: $password)
}
Variables
{"password": "abc123"}
Response
{"data": {"deleteUserData": false}}
Mutations

deleteUserFav

Response

Returns a Boolean!

Arguments
Name Description
userUuid - UUID!

Example

Query
mutation deleteUserFav($userUuid: UUID!) {
  deleteUserFav(userUuid: $userUuid)
}
Variables
{
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Response
{"data": {"deleteUserFav": false}}
Mutations

editComment

Response

Returns a Boolean!

Arguments
Name Description
data - IptEditCommentData!

Example

Query
mutation editComment($data: IptEditCommentData!) {
  editComment(data: $data)
}
Variables
{"data": IptEditCommentData}
Response
{"data": {"editComment": true}}
Mutations

getToken

Response

Returns a Token!

Example

Query
mutation getToken {
  getToken {
    bearer
  }
}
Response
{"data": {"getToken": {"bearer": "xyz789"}}}
Mutations

logout

Response

Returns a String!

Example

Query
mutation logout {
  logout
}
Response
{"data": {"logout": "abc123"}}
Mutations

putCompanyUpdate

Response

Returns an Int!

Arguments
Name Description
companyUuid - UUID!
args - IptUpdateCompanyData!

Example

Query
mutation putCompanyUpdate(
  $companyUuid: UUID!,
  $args: IptUpdateCompanyData!
) {
  putCompanyUpdate(
    companyUuid: $companyUuid,
    args: $args
  )
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "args": IptUpdateCompanyData
}
Response
{"data": {"putCompanyUpdate": 987}}
Mutations

putComponentModificationUpdate

Response

Returns an Int!

Arguments
Name Description
componentModificationUuid - UUID!
args - IptUpdateComponentModificationData!

Example

Query
mutation putComponentModificationUpdate(
  $componentModificationUuid: UUID!,
  $args: IptUpdateComponentModificationData!
) {
  putComponentModificationUpdate(
    componentModificationUuid: $componentModificationUuid,
    args: $args
  )
}
Variables
{
  "componentModificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "args": IptUpdateComponentModificationData
}
Response
{"data": {"putComponentModificationUpdate": 987}}
Mutations

putComponentParams

Response

Returns an Int!

Arguments
Name Description
args - IptComponentParamsData!

Example

Query
mutation putComponentParams($args: IptComponentParamsData!) {
  putComponentParams(args: $args)
}
Variables
{"args": IptComponentParamsData}
Response
{"data": {"putComponentParams": 987}}
Mutations

putComponentUpdate

Response

Returns an Int!

Arguments
Name Description
componentUuid - UUID!
args - IptUpdateComponentData!

Example

Query
mutation putComponentUpdate(
  $componentUuid: UUID!,
  $args: IptUpdateComponentData!
) {
  putComponentUpdate(
    componentUuid: $componentUuid,
    args: $args
  )
}
Variables
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "args": IptUpdateComponentData
}
Response
{"data": {"putComponentUpdate": 987}}
Mutations

putModificationParams

Response

Returns an Int!

Arguments
Name Description
args - IptModificationParamData!

Example

Query
mutation putModificationParams($args: IptModificationParamData!) {
  putModificationParams(args: $args)
}
Variables
{"args": IptModificationParamData}
Response
{"data": {"putModificationParams": 987}}
Mutations

putServiceParams

Response

Returns an Int!

Arguments
Name Description
args - IptServiceParamsData!

Example

Query
mutation putServiceParams($args: IptServiceParamsData!) {
  putServiceParams(args: $args)
}
Variables
{"args": IptServiceParamsData}
Response
{"data": {"putServiceParams": 123}}
Mutations

putServiceUpdate

Response

Returns an Int!

Arguments
Name Description
serviceUuid - UUID!
args - IptUpdateServiceData!

Example

Query
mutation putServiceUpdate(
  $serviceUuid: UUID!,
  $args: IptUpdateServiceData!
) {
  putServiceUpdate(
    serviceUuid: $serviceUuid,
    args: $args
  )
}
Variables
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "args": IptUpdateServiceData
}
Response
{"data": {"putServiceUpdate": 123}}
Mutations

putStandardUpdate

Response

Returns an Int!

Arguments
Name Description
standardUuid - UUID!
args - IptUpdateStandardData!

Example

Query
mutation putStandardUpdate(
  $standardUuid: UUID!,
  $args: IptUpdateStandardData!
) {
  putStandardUpdate(
    standardUuid: $standardUuid,
    args: $args
  )
}
Variables
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "args": IptUpdateStandardData
}
Response
{"data": {"putStandardUpdate": 123}}
Mutations

putUpdatePassword

Response

Returns a Boolean!

Arguments
Name Description
args - IptUpdatePassword!

Example

Query
mutation putUpdatePassword($args: IptUpdatePassword!) {
  putUpdatePassword(args: $args)
}
Variables
{"args": IptUpdatePassword}
Response
{"data": {"putUpdatePassword": true}}
Mutations

putUserUpdate

Response

Returns an Int!

Arguments
Name Description
args - IptUpdateUserData!

Example

Query
mutation putUserUpdate($args: IptUpdateUserData!) {
  putUserUpdate(args: $args)
}
Variables
{"args": IptUpdateUserData}
Response
{"data": {"putUserUpdate": 987}}
Mutations

readNotifications

Response

Returns an Int!

Arguments
Name Description
notificationsIds - [Int!]!

Example

Query
mutation readNotifications($notificationsIds: [Int!]!) {
  readNotifications(notificationsIds: $notificationsIds)
}
Variables
{"notificationsIds": [987]}
Response
{"data": {"readNotifications": 123}}
Mutations

registerCompany

Response

Returns a UUID!

Arguments
Name Description
args - IptCompanyData!

Example

Query
mutation registerCompany($args: IptCompanyData!) {
  registerCompany(args: $args)
}
Variables
{"args": IptCompanyData}
Response
{
  "data": {
    "registerCompany": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

registerCompanyRepresent

Response

Returns a UUID!

Arguments
Name Description
args - IptCompanyRepresentData!

Example

Query
mutation registerCompanyRepresent($args: IptCompanyRepresentData!) {
  registerCompanyRepresent(args: $args)
}
Variables
{"args": IptCompanyRepresentData}
Response
{
  "data": {
    "registerCompanyRepresent": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

registerCompanyRole

Response

Returns an Int!

Arguments
Name Description
args - IptRoleMemberData!

Example

Query
mutation registerCompanyRole($args: IptRoleMemberData!) {
  registerCompanyRole(args: $args)
}
Variables
{"args": IptRoleMemberData}
Response
{"data": {"registerCompanyRole": 987}}
Mutations

registerComponent

Response

Returns a UUID!

Arguments
Name Description
args - IptComponentData!

Example

Query
mutation registerComponent($args: IptComponentData!) {
  registerComponent(args: $args)
}
Variables
{"args": IptComponentData}
Response
{
  "data": {
    "registerComponent": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

registerComponentModification

Response

Returns a UUID!

Arguments
Name Description
args - IptComponentModificationData!

Example

Query
mutation registerComponentModification($args: IptComponentModificationData!) {
  registerComponentModification(args: $args)
}
Variables
{"args": IptComponentModificationData}
Response
{
  "data": {
    "registerComponentModification": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

registerComponentModificationsBulk

Response

Returns [UUID!]!

Arguments
Name Description
args - IptMultipleModificationsData!

Example

Query
mutation registerComponentModificationsBulk($args: IptMultipleModificationsData!) {
  registerComponentModificationsBulk(args: $args)
}
Variables
{"args": IptMultipleModificationsData}
Response
{
  "data": {
    "registerComponentModificationsBulk": [
      "c25ec13b-380b-48e4-ba36-fb6a5a140664"
    ]
  }
}
Mutations

registerDiscussionComment

Response

Returns a UUID!

Arguments
Name Description
args - IptDiscussionCommentData!

Example

Query
mutation registerDiscussionComment($args: IptDiscussionCommentData!) {
  registerDiscussionComment(args: $args)
}
Variables
{"args": IptDiscussionCommentData}
Response
{
  "data": {
    "registerDiscussionComment": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

registerExtension

Response

Returns an Extension!

Arguments
Name Description
args - IptExtensionData!

Example

Query
mutation registerExtension($args: IptExtensionData!) {
  registerExtension(args: $args) {
    id
    extension
    programId
  }
}
Variables
{"args": IptExtensionData}
Response
{
  "data": {
    "registerExtension": {
      "id": 123,
      "extension": "abc123",
      "programId": 123
    }
  }
}
Mutations

registerKeyword

Response

Returns a Keyword!

Arguments
Name Description
args - IptKeywordData!

Example

Query
mutation registerKeyword($args: IptKeywordData!) {
  registerKeyword(args: $args) {
    id
    keyword
  }
}
Variables
{"args": IptKeywordData}
Response
{
  "data": {
    "registerKeyword": {
      "id": 987,
      "keyword": "abc123"
    }
  }
}
Mutations

registerLicense

Response

Returns a License!

Arguments
Name Description
args - LicenseData!

Example

Query
mutation registerLicense($args: LicenseData!) {
  registerLicense(args: $args) {
    id
    name
    keyword
    publicationAt
  }
}
Variables
{"args": LicenseData}
Response
{
  "data": {
    "registerLicense": {
      "id": 123,
      "name": "abc123",
      "keyword": "abc123",
      "publicationAt": NaiveDateTime
    }
  }
}
Mutations

registerModificationFileset

Response

Returns a UUID!

Arguments
Name Description
args - IptFilesetProgramData!

Example

Query
mutation registerModificationFileset($args: IptFilesetProgramData!) {
  registerModificationFileset(args: $args)
}
Variables
{"args": IptFilesetProgramData}
Response
{
  "data": {
    "registerModificationFileset": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

registerParam

Response

Returns a ParamTranslateList!

Arguments
Name Description
args - IptParamTranslateListData!

Example

Query
mutation registerParam($args: IptParamTranslateListData!) {
  registerParam(args: $args) {
    paramId
    langId
    paramname
  }
}
Variables
{"args": IptParamTranslateListData}
Response
{
  "data": {
    "registerParam": {
      "paramId": 123,
      "langId": 123,
      "paramname": "abc123"
    }
  }
}
Mutations

registerParamsBulk

Response

Returns [ParamTranslateList!]!

Arguments
Name Description
args - [IptParamTranslateListData!]!

Example

Query
mutation registerParamsBulk($args: [IptParamTranslateListData!]!) {
  registerParamsBulk(args: $args) {
    paramId
    langId
    paramname
  }
}
Variables
{"args": [IptParamTranslateListData]}
Response
{
  "data": {
    "registerParamsBulk": [
      {
        "paramId": 123,
        "langId": 123,
        "paramname": "xyz789"
      }
    ]
  }
}
Mutations

registerProgram

Response

Returns a Program!

Arguments
Name Description
args - IptProgramData!

Example

Query
mutation registerProgram($args: IptProgramData!) {
  registerProgram(args: $args) {
    id
    name
  }
}
Variables
{"args": IptProgramData}
Response
{
  "data": {
    "registerProgram": {
      "id": 987,
      "name": "xyz789"
    }
  }
}
Mutations

registerRegion

Response

Returns a RegionTranslateList!

Arguments
Name Description
args - IptRegionTranslateListData!

Example

Query
mutation registerRegion($args: IptRegionTranslateListData!) {
  registerRegion(args: $args) {
    regionId
    langId
    region
  }
}
Variables
{"args": IptRegionTranslateListData}
Response
{
  "data": {
    "registerRegion": {
      "regionId": 987,
      "langId": 987,
      "region": "abc123"
    }
  }
}
Mutations

registerStandard

Response

Returns a UUID!

Arguments
Name Description
args - IptStandardData!

Example

Query
mutation registerStandard($args: IptStandardData!) {
  registerStandard(args: $args)
}
Variables
{"args": IptStandardData}
Response
{
  "data": {
    "registerStandard": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

registerUser

Response

Returns a SlimUser!

Arguments
Name Description
args - IptUserData!

Example

Query
mutation registerUser($args: IptUserData!) {
  registerUser(args: $args) {
    uuid
    username
    programId
  }
}
Variables
{"args": IptUserData}
Response
{
  "data": {
    "registerUser": {
      "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "username": "xyz789",
      "programId": 987
    }
  }
}
Mutations

rotateApiKey

Response

Returns a String!

Arguments
Name Description
keyId - Int!

Example

Query
mutation rotateApiKey($keyId: Int!) {
  rotateApiKey(keyId: $keyId)
}
Variables
{"keyId": 987}
Response
{"data": {"rotateApiKey": "xyz789"}}
Mutations

serviceRequest

Response

Returns a UUID!

Arguments
Name Description
args - IptServiceData!
newUser - IptUserData

Example

Query
mutation serviceRequest(
  $args: IptServiceData!,
  $newUser: IptUserData
) {
  serviceRequest(
    args: $args,
    newUser: $newUser
  )
}
Variables
{
  "args": IptServiceData,
  "newUser": IptUserData
}
Response
{
  "data": {
    "serviceRequest": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  }
}
Mutations

setCompanyAccessComponent

Response

Returns a Boolean!

Arguments
Name Description
args - IptCompanyAccessComponentData!

Example

Query
mutation setCompanyAccessComponent($args: IptCompanyAccessComponentData!) {
  setCompanyAccessComponent(args: $args)
}
Variables
{"args": IptCompanyAccessComponentData}
Response
{"data": {"setCompanyAccessComponent": false}}
Mutations

setCompanyAccessService

Response

Returns a Boolean!

Arguments
Name Description
args - IptCompanyAccessServiceData!

Example

Query
mutation setCompanyAccessService($args: IptCompanyAccessServiceData!) {
  setCompanyAccessService(args: $args)
}
Variables
{"args": IptCompanyAccessServiceData}
Response
{"data": {"setCompanyAccessService": true}}
Mutations

setCompanyAccessStandard

Response

Returns a Boolean!

Arguments
Name Description
args - IptCompanyAccessStandardData!

Example

Query
mutation setCompanyAccessStandard($args: IptCompanyAccessStandardData!) {
  setCompanyAccessStandard(args: $args)
}
Variables
{"args": IptCompanyAccessStandardData}
Response
{"data": {"setCompanyAccessStandard": true}}
Mutations

setCompanyOwnerSupplier

Response

Returns a Boolean!

Arguments
Name Description
args - IptSupplierComponentData!

Example

Query
mutation setCompanyOwnerSupplier($args: IptSupplierComponentData!) {
  setCompanyOwnerSupplier(args: $args)
}
Variables
{"args": IptSupplierComponentData}
Response
{"data": {"setCompanyOwnerSupplier": false}}
Mutations

setUserAccessComponent

Response

Returns a Boolean!

Arguments
Name Description
args - IptUserAccessComponentData!

Example

Query
mutation setUserAccessComponent($args: IptUserAccessComponentData!) {
  setUserAccessComponent(args: $args)
}
Variables
{"args": IptUserAccessComponentData}
Response
{"data": {"setUserAccessComponent": true}}
Mutations

setUserAccessService

Response

Returns a Boolean!

Arguments
Name Description
args - IptUserAccessServiceData!

Example

Query
mutation setUserAccessService($args: IptUserAccessServiceData!) {
  setUserAccessService(args: $args)
}
Variables
{"args": IptUserAccessServiceData}
Response
{"data": {"setUserAccessService": false}}
Mutations

setUserAccessStandard

Response

Returns a Boolean!

Arguments
Name Description
args - IptUserAccessStandardData!

Example

Query
mutation setUserAccessStandard($args: IptUserAccessStandardData!) {
  setUserAccessStandard(args: $args)
}
Variables
{"args": IptUserAccessStandardData}
Response
{"data": {"setUserAccessStandard": false}}
Mutations

transferComponentOwnership

Response

Returns a Boolean!

Arguments
Name Description
args - ChangeOwnerComponent!

Example

Query
mutation transferComponentOwnership($args: ChangeOwnerComponent!) {
  transferComponentOwnership(args: $args)
}
Variables
{"args": ChangeOwnerComponent}
Response
{"data": {"transferComponentOwnership": false}}
Mutations

transferServiceOwnership

Response

Returns a Boolean!

Arguments
Name Description
args - ChangeOwnerService!

Example

Query
mutation transferServiceOwnership($args: ChangeOwnerService!) {
  transferServiceOwnership(args: $args)
}
Variables
{"args": ChangeOwnerService}
Response
{"data": {"transferServiceOwnership": false}}
Mutations

transferStandardOwnership

Response

Returns a Boolean!

Arguments
Name Description
args - ChangeOwnerStandard!

Example

Query
mutation transferStandardOwnership($args: ChangeOwnerStandard!) {
  transferStandardOwnership(args: $args)
}
Variables
{"args": ChangeOwnerStandard}
Response
{"data": {"transferStandardOwnership": false}}
Mutations

updateApiKey

Response

Returns an Int!

Arguments
Name Description
keyId - Int!
args - IptUpdateApiKeyData!

Example

Query
mutation updateApiKey(
  $keyId: Int!,
  $args: IptUpdateApiKeyData!
) {
  updateApiKey(
    keyId: $keyId,
    args: $args
  )
}
Variables
{"keyId": 987, "args": IptUpdateApiKeyData}
Response
{"data": {"updateApiKey": 987}}
Mutations

updateCompanyCertificate

Response

Returns a Boolean!

Arguments
Name Description
args - IptUpdateCompanyCertificateData!

Example

Query
mutation updateCompanyCertificate($args: IptUpdateCompanyCertificateData!) {
  updateCompanyCertificate(args: $args)
}
Variables
{"args": IptUpdateCompanyCertificateData}
Response
{"data": {"updateCompanyCertificate": false}}
Mutations

updateCompanyRepresent

Response

Returns an Int!

Arguments
Name Description
companyUuid - UUID!
companyRepresentUuid - UUID!
args - IptUpdateCompanyRepresentData!

Example

Query
mutation updateCompanyRepresent(
  $companyUuid: UUID!,
  $companyRepresentUuid: UUID!,
  $args: IptUpdateCompanyRepresentData!
) {
  updateCompanyRepresent(
    companyUuid: $companyUuid,
    companyRepresentUuid: $companyRepresentUuid,
    args: $args
  )
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companyRepresentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "args": IptUpdateCompanyRepresentData
}
Response
{"data": {"updateCompanyRepresent": 987}}
Mutations

updateToken

Response

Returns a Token!

Example

Query
mutation updateToken {
  updateToken {
    bearer
  }
}
Response
{
  "data": {
    "updateToken": {"bearer": "xyz789"}
  }
}
Mutations

updateUserCertificate

Response

Returns a Boolean!

Arguments
Name Description
args - IptUpdateUserCertificateData!

Example

Query
mutation updateUserCertificate($args: IptUpdateUserCertificateData!) {
  updateUserCertificate(args: $args)
}
Variables
{"args": IptUpdateUserCertificateData}
Response
{"data": {"updateUserCertificate": false}}
Mutations

uploadCompanyCertificate

Response

Returns an UploadFile!

Arguments
Name Description
certData - IptCompanyCertificateData!

Example

Query
mutation uploadCompanyCertificate($certData: IptCompanyCertificateData!) {
  uploadCompanyCertificate(certData: $certData) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{"certData": IptCompanyCertificateData}
Response
{
  "data": {
    "uploadCompanyCertificate": {
      "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "filename": "xyz789",
      "uploadUrl": "abc123"
    }
  }
}
Mutations

uploadCompanyFavicon

Response

Returns an UploadFile!

Arguments
Name Description
companyUuid - UUID!
filename - String!

Example

Query
mutation uploadCompanyFavicon(
  $companyUuid: UUID!,
  $filename: String!
) {
  uploadCompanyFavicon(
    companyUuid: $companyUuid,
    filename: $filename
  ) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filename": "xyz789"
}
Response
{
  "data": {
    "uploadCompanyFavicon": {
      "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "filename": "abc123",
      "uploadUrl": "abc123"
    }
  }
}
Mutations

uploadCompleted

Response

Returns an Int!

Arguments
Name Description
fileUuids - [UUID!]!

Example

Query
mutation uploadCompleted($fileUuids: [UUID!]!) {
  uploadCompleted(fileUuids: $fileUuids)
}
Variables
{
  "fileUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Response
{"data": {"uploadCompleted": 987}}
Mutations

uploadComponentFavicon

Response

Returns an UploadFile!

Arguments
Name Description
args - IptComponentFaviconData!

Example

Query
mutation uploadComponentFavicon($args: IptComponentFaviconData!) {
  uploadComponentFavicon(args: $args) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{"args": IptComponentFaviconData}
Response
{
  "data": {
    "uploadComponentFavicon": {
      "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "filename": "xyz789",
      "uploadUrl": "xyz789"
    }
  }
}
Mutations

uploadComponentFiles

Response

Returns [UploadFile!]!

Arguments
Name Description
args - IptComponentFilesData!

Example

Query
mutation uploadComponentFiles($args: IptComponentFilesData!) {
  uploadComponentFiles(args: $args) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{"args": IptComponentFilesData}
Response
{
  "data": {
    "uploadComponentFiles": [
      {
        "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "filename": "xyz789",
        "uploadUrl": "xyz789"
      }
    ]
  }
}
Mutations

uploadFavicon

Response

Returns an UploadFile!

Arguments
Name Description
filename - String!

Example

Query
mutation uploadFavicon($filename: String!) {
  uploadFavicon(filename: $filename) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{"filename": "xyz789"}
Response
{
  "data": {
    "uploadFavicon": {
      "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "filename": "abc123",
      "uploadUrl": "abc123"
    }
  }
}
Mutations

uploadFilesToFileset

Response

Returns [UploadFile!]!

Arguments
Name Description
args - IptModificationFileFromFilesetData!

Example

Query
mutation uploadFilesToFileset($args: IptModificationFileFromFilesetData!) {
  uploadFilesToFileset(args: $args) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{"args": IptModificationFileFromFilesetData}
Response
{
  "data": {
    "uploadFilesToFileset": [
      {
        "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "filename": "abc123",
        "uploadUrl": "xyz789"
      }
    ]
  }
}
Mutations

uploadModificationFiles

Response

Returns [UploadFile!]!

Arguments
Name Description
args - IptModificationFilesData!

Example

Query
mutation uploadModificationFiles($args: IptModificationFilesData!) {
  uploadModificationFiles(args: $args) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{"args": IptModificationFilesData}
Response
{
  "data": {
    "uploadModificationFiles": [
      {
        "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "filename": "xyz789",
        "uploadUrl": "abc123"
      }
    ]
  }
}
Mutations

uploadServiceFiles

Response

Returns [UploadFile!]!

Arguments
Name Description
args - IptServiceFilesData!

Example

Query
mutation uploadServiceFiles($args: IptServiceFilesData!) {
  uploadServiceFiles(args: $args) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{"args": IptServiceFilesData}
Response
{
  "data": {
    "uploadServiceFiles": [
      {
        "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "filename": "xyz789",
        "uploadUrl": "abc123"
      }
    ]
  }
}
Mutations

uploadStandardFavicon

Response

Returns an UploadFile!

Arguments
Name Description
args - IptStandardFaviconData!

Example

Query
mutation uploadStandardFavicon($args: IptStandardFaviconData!) {
  uploadStandardFavicon(args: $args) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{"args": IptStandardFaviconData}
Response
{
  "data": {
    "uploadStandardFavicon": {
      "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "filename": "xyz789",
      "uploadUrl": "abc123"
    }
  }
}
Mutations

uploadStandardFiles

Response

Returns [UploadFile!]!

Arguments
Name Description
args - IptStandardFilesData!

Example

Query
mutation uploadStandardFiles($args: IptStandardFilesData!) {
  uploadStandardFiles(args: $args) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{"args": IptStandardFilesData}
Response
{
  "data": {
    "uploadStandardFiles": [
      {
        "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
        "filename": "abc123",
        "uploadUrl": "abc123"
      }
    ]
  }
}
Mutations

uploadUserCertificate

Response

Returns an UploadFile!

Arguments
Name Description
certData - IptUserCertificateData!

Example

Query
mutation uploadUserCertificate($certData: IptUserCertificateData!) {
  uploadUserCertificate(certData: $certData) {
    fileUuid
    filename
    uploadUrl
  }
}
Variables
{"certData": IptUserCertificateData}
Response
{
  "data": {
    "uploadUserCertificate": {
      "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
      "filename": "xyz789",
      "uploadUrl": "abc123"
    }
  }
}

Types

AccessCheckResult

Fields
Field Name Description
hasAccess - Boolean!
accessLevel - Int
source - AccessSource!
Example
{"hasAccess": true, "accessLevel": 123, "source": "OWNER"}
Types

AccessSource

Values
Enum Value Description

OWNER

DIRECT_ACCESS

COMPANY_ROLE

PUBLIC

NONE
Example
"OWNER"
Types

ActualStatusTranslateList

Fields
Field Name Description
actualStatusId - Int!
langId - Int!
name - String!
Example
{
  "actualStatusId": 123,
  "langId": 123,
  "name": "abc123"
}
Types

ApiKeyData

Fields
Field Name Description
id - Int!
userUuid - UUID!
name - String!
lastUsedAt - DateTime
expiresAt - DateTime!
isActive - Boolean!
createdAt - DateTime!
Example
{
  "id": 123,
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "name": "xyz789",
  "lastUsedAt": "2007-12-03T10:15:30Z",
  "expiresAt": "2007-12-03T10:15:30Z",
  "isActive": true,
  "createdAt": "2007-12-03T10:15:30Z"
}
Types

Boolean

Description

The Boolean scalar type represents true or false.

Example
true
Types

ChangeOwnerComponent

Fields
Input Field Description
componentUuid - UUID!
newOwnerUserUuid - UUID!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "newOwnerUserUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

ChangeOwnerService

Fields
Input Field Description
serviceUuid - UUID!
newOwnerUserUuid - UUID!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "newOwnerUserUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

ChangeOwnerStandard

Fields
Input Field Description
standardUuid - UUID!
newOwnerUserUuid - UUID!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "newOwnerUserUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

ChangeTypeAccessCompany

Fields
Input Field Description
companyUuid - UUID!
newTypeAccessId - Int!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "newTypeAccessId": 123
}
Types

ChangeTypeAccessComponent

Fields
Input Field Description
componentUuid - UUID!
newTypeAccessId - Int!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "newTypeAccessId": 987
}
Types

ChangeTypeAccessService

Fields
Input Field Description
serviceUuid - UUID!
newTypeAccessId - Int!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "newTypeAccessId": 987
}
Types

ChangeTypeAccessStandard

Fields
Input Field Description
standardUuid - UUID!
newTypeAccessId - Int!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "newTypeAccessId": 123
}
Types

Char

Example
Char
Types

Claims

Fields
Field Name Description
iss - String!
username - String!
sub - UUID!
iat - String!
exp - String!
programId - Int!
Example
{
  "iss": "xyz789",
  "username": "abc123",
  "sub": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "iat": "xyz789",
  "exp": "xyz789",
  "programId": 987
}
Types

CompanyAccessComponentAndRelatedData

Fields
Field Name Description
componentUuid - UUID!
company - ShowCompanyShort!
permission - PermissionTranslateList!
isEnabled - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "company": ShowCompanyShort,
  "permission": PermissionTranslateList,
  "isEnabled": true,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime
}
Types

CompanyAccessServiceAndRelatedData

Fields
Field Name Description
serviceUuid - UUID!
company - ShowCompanyShort!
permission - PermissionTranslateList!
isEnabled - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "company": ShowCompanyShort,
  "permission": PermissionTranslateList,
  "isEnabled": true,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime
}
Types

CompanyAccessStandardAndRelatedData

Fields
Field Name Description
standardUuid - UUID!
company - ShowCompanyShort!
permission - PermissionTranslateList!
isEnabled - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "company": ShowCompanyShort,
  "permission": PermissionTranslateList,
  "isEnabled": true,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime
}
Types

CompanyAndRelatedData

Fields
Field Name Description
uuid - UUID!
orgname - String!
shortname - String!
inn - String!
phone - String!
email - String!
description - String!
address - String!
siteUrl - String!
timeZone - String!
ownerUser - ShowUserShort!
imageFile - DownloadFile!
region - RegionTranslateList!
companyRepresents - [CompanyRepresentAndRelatedData!]!
companyType - CompanyTypeTranslateList!
companyCertificates - [CompanyCertificateAndFile!]!
companySpecs - [SpecTranslateList!]!
typeAccess - TypeAccessTranslateList!
isSupplier - Boolean!
isEmailVerified - Boolean!
subscribers - Int!
isFollowed - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "orgname": "xyz789",
  "shortname": "xyz789",
  "inn": "abc123",
  "phone": "xyz789",
  "email": "xyz789",
  "description": "abc123",
  "address": "xyz789",
  "siteUrl": "abc123",
  "timeZone": "abc123",
  "ownerUser": ShowUserShort,
  "imageFile": DownloadFile,
  "region": RegionTranslateList,
  "companyRepresents": [CompanyRepresentAndRelatedData],
  "companyType": CompanyTypeTranslateList,
  "companyCertificates": [CompanyCertificateAndFile],
  "companySpecs": [SpecTranslateList],
  "typeAccess": TypeAccessTranslateList,
  "isSupplier": false,
  "isEmailVerified": false,
  "subscribers": 123,
  "isFollowed": false,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime
}
Types

CompanyCertificateAndFile

Fields
Field Name Description
file - DownloadFile!
companyUuid - UUID!
description - String!
Example
{
  "file": DownloadFile,
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "description": "xyz789"
}
Types

CompanyMemberAndRelatedData

Fields
Field Name Description
companyUuid - UUID!
user - ShowUserShort!
companyRole - RoleMemberAndRelatedData!
isEnabled - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "user": ShowUserShort,
  "companyRole": RoleMemberAndRelatedData,
  "isEnabled": false,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime
}
Types

CompanyRepresentAndRelatedData

Fields
Field Name Description
uuid - UUID!
companyUuid - UUID!
region - RegionTranslateList!
representationType - RepresentationTypeTranslateList!
name - String!
address - String!
phone - String!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "region": RegionTranslateList,
  "representationType": RepresentationTypeTranslateList,
  "name": "xyz789",
  "address": "abc123",
  "phone": "xyz789"
}
Types

CompanyTypeTranslateList

Fields
Field Name Description
companyTypeId - Int!
langId - Int!
name - String!
shortname - String!
Example
{
  "companyTypeId": 123,
  "langId": 987,
  "name": "xyz789",
  "shortname": "xyz789"
}
Types

ComponentAndRelatedData

Fields
Field Name Description
uuid - UUID!
parentComponentUuid - UUID!
name - String!
description - String!
imageFile - DownloadFile!
ownerUser - ShowUserShort!
typeAccess - TypeAccessTranslateList!
componentType - ComponentTypeTranslateList!
actualStatus - ActualStatusTranslateList!
isBase - Boolean!
subscribers - Int!
isFollowed - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
licenses - [License!]!
componentParams - [ComponentParamWithTranslation!]!
Arguments
sort - IptSort
paginate - IptPaginate
paramsCount - Int!
files - [ShowFileRelatedData!]!
Arguments
sort - IptSort
paginate - IptPaginate
filesCount - Int!
componentSpecs - [SpecTranslateList!]!
Arguments
paginate - IptPaginate
componentKeywords - [Keyword!]!
Arguments
paginate - IptPaginate
componentModifications - [ComponentModificationAndRelatedData!]!
Arguments
filter - [UUID!]
sort - IptSort
paginate - IptPaginate
modificationsCount - Int!
componentSuppliers - [ComponentSupplierRelatedData!]!
Arguments
paginate - IptPaginate
suppliersCount - Int!
componentStandards - [ShowStandardShort!]!
Arguments
paginate - IptPaginate
standardsCount - Int!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "parentComponentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "name": "xyz789",
  "description": "xyz789",
  "imageFile": DownloadFile,
  "ownerUser": ShowUserShort,
  "typeAccess": TypeAccessTranslateList,
  "componentType": ComponentTypeTranslateList,
  "actualStatus": ActualStatusTranslateList,
  "isBase": false,
  "subscribers": 987,
  "isFollowed": false,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime,
  "licenses": [License],
  "componentParams": [ComponentParamWithTranslation],
  "paramsCount": 123,
  "files": [ShowFileRelatedData],
  "filesCount": 123,
  "componentSpecs": [SpecTranslateList],
  "componentKeywords": [Keyword],
  "componentModifications": [
    ComponentModificationAndRelatedData
  ],
  "modificationsCount": 987,
  "componentSuppliers": [ComponentSupplierRelatedData],
  "suppliersCount": 123,
  "componentStandards": [ShowStandardShort],
  "standardsCount": 987
}
Types

ComponentModificationAndRelatedData

Fields
Field Name Description
uuid - UUID!
componentUuid - UUID!
parentModificationUuid - UUID!
modificationName - String!
description - String!
actualStatus - ActualStatusTranslateList!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
filesetsForProgram - [FilesetProgramRelatedData!]!
filesetsCount - Int!
modificationParams - [ModificationParamWithTranslation!]!
Arguments
sort - IptSort
paginate - IptPaginate
paramsCount - Int!
files - [ShowFileRelatedData!]!
Arguments
sort - IptSort
paginate - IptPaginate
filesCount - Int!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "parentModificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "modificationName": "abc123",
  "description": "xyz789",
  "actualStatus": ActualStatusTranslateList,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime,
  "filesetsForProgram": [FilesetProgramRelatedData],
  "filesetsCount": 987,
  "modificationParams": [
    ModificationParamWithTranslation
  ],
  "paramsCount": 987,
  "files": [ShowFileRelatedData],
  "filesCount": 123
}
Types

ComponentParamWithTranslation

Fields
Field Name Description
componentUuid - UUID!
param - ParamTranslateList!
value - String!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "param": ParamTranslateList,
  "value": "xyz789"
}
Types

ComponentSupplierRelatedData

Fields
Field Name Description
supplier - SlimCompany!
componentUuid - UUID!
description - String!
Example
{
  "supplier": SlimCompany,
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "description": "xyz789"
}
Types

ComponentTypeTranslateList

Fields
Field Name Description
componentTypeId - Int!
langId - Int!
componentType - String!
Example
{
  "componentTypeId": 123,
  "langId": 123,
  "componentType": "xyz789"
}
Types

DateTime

Example
"2007-12-03T10:15:30Z"
Types

DegreeImportanceTranslateList

Fields
Field Name Description
degreeImportanceId - Int!
langId - Int!
degree - String!
Example
{
  "degreeImportanceId": 123,
  "langId": 123,
  "degree": "abc123"
}
Types

DelCompanyAccessComponentData

Fields
Input Field Description
componentUuid - UUID!
companyUuid - UUID!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelCompanyAccessServiceData

Fields
Input Field Description
serviceUuid - UUID!
companyUuid - UUID!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelCompanyAccessStandardData

Fields
Input Field Description
standardUuid - UUID!
companyUuid - UUID!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelCompanyCertificateData

Fields
Input Field Description
companyUuid - UUID!
fileUuid - UUID!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelCompanyMemberData

Fields
Input Field Description
companyUuid - UUID!
userUuid - UUID!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelCompanyOfSuppliersData

Fields
Input Field Description
companyUuid - UUID!
componentUuid - UUID!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelComponentFileData

Fields
Input Field Description
fileUuid - UUID!
componentUuid - UUID!
Example
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelComponentModificationData

Fields
Input Field Description
componentUuid - UUID!
modificationUuid - UUID!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelComponentParamData

Fields
Input Field Description
componentUuid - UUID!
paramIds - [Int!]!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paramIds": [123]
}
Types

DelFilesetProgramData

Fields
Input Field Description
modificationUuid - UUID!
filesetUuid - UUID!
Example
{
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filesetUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelModificationFileData

Fields
Input Field Description
fileUuid - UUID!
modificationUuid - UUID!
Example
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelModificationFileFromFilesetData

Fields
Input Field Description
filesetUuid - UUID!
fileUuids - [UUID!]!
Example
{
  "filesetUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "fileUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

DelModificationParamData

Fields
Input Field Description
modificationUuid - UUID!
paramIds - [Int!]!
Example
{
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paramIds": [123]
}
Types

DelRoleAccessData

Fields
Input Field Description
roleId - Int!
typesAccessIds - [Int!]!
Example
{"roleId": 987, "typesAccessIds": [987]}
Types

DelRoleMemberData

Fields
Input Field Description
companyUuid - UUID!
roleId - Int!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "roleId": 987
}
Types

DelServiceParamData

Fields
Input Field Description
serviceUuid - UUID!
paramIds - [Int!]!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "paramIds": [987]
}
Types

DelStandardToComponentData

Fields
Input Field Description
standardsUuids - [UUID!]!
componentUuid - UUID!
Example
{
  "standardsUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ],
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelSuppliersComponentData

Fields
Input Field Description
componentUuid - UUID!
companiesUuids - [UUID!]!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companiesUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

DelUserAccessComponentData

Fields
Input Field Description
componentUuid - UUID!
userUuid - UUID!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelUserAccessServiceData

Fields
Input Field Description
serviceUuid - UUID!
userUuid - UUID!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelUserAccessStandardData

Fields
Input Field Description
standardUuid - UUID!
userUuid - UUID!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DelUserCertificateData

Fields
Input Field Description
fileUuid - UUID!
Example
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DeleteServiceFileData

Fields
Input Field Description
fileUuid - UUID!
serviceUuid - UUID!
Example
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DeleteStandardFileData

Fields
Input Field Description
fileUuid - UUID!
standardUuid - UUID!
Example
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

DiscussionCommentData

Fields
Field Name Description
uuid - UUID!
discussionUuid - UUID!
parentCommentUuid - UUID!
author - ShowUserShort!
messageContent - String!
isEdited - Boolean!
isHidden - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
repliesCount - Int!
replies - [DiscussionCommentData!]!
Arguments
sort - IptSort
paginate - IptPaginate
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "discussionUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "parentCommentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "author": ShowUserShort,
  "messageContent": "abc123",
  "isEdited": true,
  "isHidden": true,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime,
  "repliesCount": 123,
  "replies": [DiscussionCommentData]
}
Types

DiscussionInfo

Fields
Field Name Description
uuid - UUID!
title - String!
isPinned - Boolean!
lastActivityAt - NaiveDateTime!
createdAt - NaiveDateTime!
repliesCount - Int!
comments - [DiscussionCommentData!]!
Arguments
filterByUuids - [UUID!]
sort - IptSort
paginate - IptPaginate
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "title": "abc123",
  "isPinned": false,
  "lastActivityAt": NaiveDateTime,
  "createdAt": NaiveDateTime,
  "repliesCount": 123,
  "comments": [DiscussionCommentData]
}
Types

DownloadFile

Fields
Field Name Description
uuid - UUID!
hash - String!
sha256Hash - String!
filename - String!
filesize - Int!
downloadUrl - String!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "hash": "xyz789",
  "sha256Hash": "xyz789",
  "filename": "abc123",
  "filesize": 987,
  "downloadUrl": "xyz789"
}
Types

Extension

Fields
Field Name Description
id - Int!
extension - String!
programId - Int!
Example
{
  "id": 987,
  "extension": "abc123",
  "programId": 123
}
Types

FilesetProgramRelatedData

Fields
Field Name Description
uuid - UUID!
modificationUuid - UUID!
program - Program!
files - [ShowFileRelatedData!]!
Arguments
sort - IptSort
paginate - IptPaginate
filesCount - Int!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "program": Program,
  "files": [ShowFileRelatedData],
  "filesCount": 987
}
Types

Int

Description

The Int scalar type represents non-fractional signed whole numeric values. Int can represent values between -(2^31) and 2^31 - 1.

Example
123
Types

IptCompaniesArg

Fields
Input Field Description
companiesUuids - [UUID!]
userUuid - UUID
favorite - Boolean
supplier - Boolean
search - String
excludeUuids - [UUID!]
Example
{
  "companiesUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ],
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "favorite": true,
  "supplier": false,
  "search": "abc123",
  "excludeUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

IptCompanyAccessComponentData

Fields
Input Field Description
componentUuid - UUID!
companyUuid - UUID!
typeAccessId - Int!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "typeAccessId": 987
}
Types

IptCompanyAccessServiceData

Fields
Input Field Description
serviceUuid - UUID!
companyUuid - UUID!
typeAccessId - Int!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "typeAccessId": 123
}
Types

IptCompanyAccessStandardData

Fields
Input Field Description
standardUuid - UUID!
companyUuid - UUID!
typeAccessId - Int!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "typeAccessId": 987
}
Types

IptCompanyCertificateData

Fields
Input Field Description
companyUuid - UUID!
description - String!
filename - String!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "description": "abc123",
  "filename": "abc123"
}
Types

IptCompanyData

Fields
Input Field Description
orgname - String!
shortname - String!
inn - String!
phone - String!
email - String!
description - String!
address - String!
siteUrl - String!
timeZone - String!
regionId - Int!
companyTypeId - Int!
typeAccessId - Int!
Example
{
  "orgname": "abc123",
  "shortname": "abc123",
  "inn": "xyz789",
  "phone": "xyz789",
  "email": "xyz789",
  "description": "abc123",
  "address": "xyz789",
  "siteUrl": "abc123",
  "timeZone": "abc123",
  "regionId": 987,
  "companyTypeId": 123,
  "typeAccessId": 123
}
Types

IptCompanyMemberData

Fields
Input Field Description
companyUuid - UUID!
userUuid - UUID!
roleId - Int!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "roleId": 123
}
Types

IptCompanyRepresentData

Fields
Input Field Description
companyUuid - UUID!
regionId - Int!
representationTypeId - Int!
name - String!
address - String!
phone - String!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "regionId": 987,
  "representationTypeId": 987,
  "name": "xyz789",
  "address": "xyz789",
  "phone": "xyz789"
}
Types

IptCompanyRepresentsArg

Fields
Input Field Description
companyUuid - UUID
representsUuids - [UUID!]
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "representsUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

IptCompanySpecsData

Fields
Input Field Description
companyUuid - UUID!
specIds - [Int!]!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "specIds": [987]
}
Types

IptComponentData

Fields
Input Field Description
parentComponentUuid - UUID
name - String!
description - String!
typeAccessId - Int!
componentTypeId - Int!
actualStatusId - Int!
isBase - Boolean!
Example
{
  "parentComponentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "name": "xyz789",
  "description": "abc123",
  "typeAccessId": 987,
  "componentTypeId": 123,
  "actualStatusId": 123,
  "isBase": false
}
Types

IptComponentFaviconData

Fields
Input Field Description
filename - String!
componentUuid - UUID!
Example
{
  "filename": "xyz789",
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

IptComponentFilesArg

Fields
Input Field Description
componentUuid - UUID!
filesUuids - [UUID!]
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filesUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

IptComponentFilesData

Fields
Input Field Description
filenames - [String!]!
componentUuid - UUID!
commitMsg - String!
Example
{
  "filenames": ["abc123"],
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "commitMsg": "abc123"
}
Types

IptComponentKeywordsData

Fields
Input Field Description
componentUuid - UUID!
keywordIds - [Int!]!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "keywordIds": [123]
}
Types

IptComponentKeywordsNames

Fields
Input Field Description
componentUuid - UUID!
keywords - [String!]!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "keywords": ["abc123"]
}
Types

IptComponentLicenseData

Fields
Input Field Description
componentUuid - UUID!
licenseId - Int!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "licenseId": 987
}
Types

IptComponentModificationData

Fields
Input Field Description
componentUuid - UUID!
parentModificationUuid - UUID
modificationName - String!
description - String!
actualStatusId - Int!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "parentModificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "modificationName": "abc123",
  "description": "xyz789",
  "actualStatusId": 123
}
Types

IptComponentParamsData

Fields
Input Field Description
componentUuid - UUID!
params - [IptParamData!]!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "params": [IptParamData]
}
Types

IptComponentSpecsData

Fields
Input Field Description
componentUuid - UUID!
specIds - [Int!]!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "specIds": [987]
}
Types

IptComponentsArg

Fields
Input Field Description
componentsUuids - [UUID!]
companyUuid - UUID
standardUuid - UUID
serviceUuid - UUID
userUuid - UUID
specId - Int
favorite - Boolean
Example
{
  "componentsUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ],
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "specId": 987,
  "favorite": true
}
Types

IptDiscussionArg

Fields
Input Field Description
objectUuid - UUID!
toObject - ToObject!
Example
{
  "objectUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "toObject": "COMPANY"
}
Types

IptDiscussionCommentData

Fields
Input Field Description
objectDiscussion - IptDiscussionArg!
discussionUuid - UUID
parentCommentUuid - UUID
messageContent - String!
Example
{
  "objectDiscussion": IptDiscussionArg,
  "discussionUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "parentCommentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "messageContent": "xyz789"
}
Types

IptDiscussionCommentsArg

Fields
Input Field Description
discussionUuid - UUID!
filterByParentUuid - UUID
filterByUuids - [UUID!]
Example
{
  "discussionUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filterByParentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filterByUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

IptEditCommentData

Fields
Input Field Description
commentUuid - UUID!
updatedMessage - String!
Example
{
  "commentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "updatedMessage": "xyz789"
}
Types

IptExtensionData

Fields
Input Field Description
extension - String!
programId - Int!
Example
{"extension": "xyz789", "programId": 123}
Types

IptFileOfFilesetArg

Fields
Input Field Description
filesetUuid - UUID!
fileUuids - [UUID!]
Example
{
  "filesetUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "fileUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

IptFilesetProgramArg

Fields
Input Field Description
modificationUuid - UUID!
programIds - [Int!]
Example
{
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "programIds": [987]
}
Types

IptFilesetProgramData

Fields
Input Field Description
modificationUuid - UUID!
programId - Int!
Example
{
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "programId": 123
}
Types

IptGetUserArg

Fields
Input Field Description
userUuid - UUID
username - String
Example
{
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "username": "abc123"
}
Types

IptKeywordData

Fields
Input Field Description
keyword - String!
Example
{"keyword": "xyz789"}
Types

IptModificationFileFromFilesetData

Fields
Input Field Description
filesetUuid - UUID!
filenames - [String!]!
commitMsg - String!
Example
{
  "filesetUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filenames": ["abc123"],
  "commitMsg": "abc123"
}
Types

IptModificationFilesArg

Fields
Input Field Description
modificationUuid - UUID!
filesUuids - [UUID!]
Example
{
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filesUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

IptModificationFilesData

Fields
Input Field Description
filenames - [String!]!
modificationUuid - UUID!
commitMsg - String!
Example
{
  "filenames": ["abc123"],
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "commitMsg": "abc123"
}
Types

IptModificationParamData

Fields
Input Field Description
modificationUuid - UUID!
params - [IptParamData!]!
Example
{
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "params": [IptParamData]
}
Types

IptModificationsData

Fields
Input Field Description
modificationName - String!
description - String!
actualStatusId - Int!
parameters - [IptParamData!]!
Example
{
  "modificationName": "xyz789",
  "description": "xyz789",
  "actualStatusId": 987,
  "parameters": [IptParamData]
}
Types

IptMultipleModificationsData

Fields
Input Field Description
componentUuid - UUID!
modificationsData - [IptModificationsData!]!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "modificationsData": [IptModificationsData]
}
Types

IptObjectDiscussionsArg

Fields
Input Field Description
objectUuid - UUID!
toObject - ToObject!
filterByUuids - [UUID!]
Example
{
  "objectUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "toObject": "COMPANY",
  "filterByUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

IptPaginate

Fields
Input Field Description
currentPage - Int!
perPage - Int!
Example
{"currentPage": 123, "perPage": 123}
Types

IptParamData

Fields
Input Field Description
paramId - Int!
value - String!
Example
{"paramId": 123, "value": "xyz789"}
Types

IptParamTranslateListData

Fields
Input Field Description
langId - Int!
paramname - String!
Example
{"langId": 987, "paramname": "abc123"}
Types

IptProgramData

Fields
Input Field Description
name - String!
Example
{"name": "abc123"}
Types

IptRegionTranslateListData

Fields
Input Field Description
langId - Int!
region - String!
Example
{"langId": 987, "region": "xyz789"}
Types

IptRoleAccessData

Fields
Input Field Description
roleId - Int!
typesAccessIds - [Int!]!
Example
{"roleId": 123, "typesAccessIds": [123]}
Types

IptRoleMemberData

Fields
Input Field Description
companyUuid - UUID!
langId - Int!
name - String!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "langId": 987,
  "name": "abc123"
}
Types

IptSearchArg

Fields
Input Field Description
search - String!
byParams - Boolean!
bySpecs - Boolean!
byKeywords - Boolean!
byModifications - Boolean!
byModificationParams - Boolean!
companyUuid - UUID
standardUuid - UUID
serviceUuid - UUID
userUuid - UUID
specId - Int
favorite - Boolean!
Example
{
  "search": "xyz789",
  "byParams": true,
  "bySpecs": false,
  "byKeywords": true,
  "byModifications": false,
  "byModificationParams": false,
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "specId": 123,
  "favorite": false
}
Types

IptSearchSpecArg

Fields
Input Field Description
text - String!
splitChar - Char
depthLevel - Int
Example
{
  "text": "abc123",
  "splitChar": Char,
  "depthLevel": 123
}
Types

IptServiceData

Fields
Input Field Description
name - String!
description - String!
companyUuid - UUID!
regionId - Int!
Example
{
  "name": "xyz789",
  "description": "xyz789",
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "regionId": 987
}
Types

IptServiceFilesArg

Fields
Input Field Description
serviceUuid - UUID!
filesUuids - [UUID!]
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filesUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

IptServiceFilesData

Fields
Input Field Description
filenames - [String!]!
serviceUuid - UUID!
commitMsg - String!
Example
{
  "filenames": ["abc123"],
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "commitMsg": "abc123"
}
Types

IptServiceKeywordsData

Fields
Input Field Description
serviceUuid - UUID!
keywordIds - [Int!]!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "keywordIds": [123]
}
Types

IptServiceKeywordsNames

Fields
Input Field Description
serviceUuid - UUID!
keywords - [String!]!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "keywords": ["xyz789"]
}
Types

IptServiceParamsData

Fields
Input Field Description
serviceUuid - UUID!
params - [IptParamData!]!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "params": [IptParamData]
}
Types

IptServiceSpecsData

Fields
Input Field Description
serviceUuid - UUID!
specIds - [Int!]!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "specIds": [123]
}
Types

IptServiceStatusArg

Fields
Input Field Description
serviceUuid - UUID!
serviceStatusId - Int!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "serviceStatusId": 987
}
Types

IptServicesArg

Fields
Input Field Description
servicesUuids - [UUID!]
companyUuid - UUID
userUuid - UUID
Example
{
  "servicesUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ],
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

IptSort

Fields
Input Field Description
byField - String!
asDesc - Boolean!
Example
{"byField": "abc123", "asDesc": false}
Types

IptSpecArg

Fields
Input Field Description
specIds - [Int!]
specsLevels - [Int!]
Example
{"specIds": [987], "specsLevels": [987]}
Types

IptSpecPathArg

Fields
Input Field Description
specIds - [Int!]
splitChar - Char
depthLevel - Int
Example
{"specIds": [123], "splitChar": Char, "depthLevel": 123}
Types

IptStandardData

Fields
Input Field Description
parentStandardUuid - UUID
name - String!
description - String!
publicationAt - NaiveDateTime!
companyUuid - UUID!
typeAccessId - Int!
standardStatusId - Int!
Example
{
  "parentStandardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "name": "xyz789",
  "description": "abc123",
  "publicationAt": NaiveDateTime,
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "typeAccessId": 987,
  "standardStatusId": 123
}
Types

IptStandardFaviconData

Fields
Input Field Description
filename - String!
standardUuid - UUID!
Example
{
  "filename": "abc123",
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

IptStandardFilesArg

Fields
Input Field Description
standardUuid - UUID!
filesUuids - [UUID!]
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filesUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

IptStandardFilesData

Fields
Input Field Description
filenames - [String!]!
standardUuid - UUID!
commitMsg - String!
Example
{
  "filenames": ["abc123"],
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "commitMsg": "abc123"
}
Types

IptStandardKeywordsData

Fields
Input Field Description
standardUuid - UUID!
keywordIds - [Int!]!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "keywordIds": [123]
}
Types

IptStandardKeywordsNames

Fields
Input Field Description
standardUuid - UUID!
keywords - [String!]!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "keywords": ["xyz789"]
}
Types

IptStandardSpecsData

Fields
Input Field Description
standardUuid - UUID!
specIds - [Int!]!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "specIds": [987]
}
Types

IptStandardToComponentData

Fields
Input Field Description
standardUuid - UUID!
componentUuid - UUID!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664"
}
Types

IptStandardsArg

Fields
Input Field Description
standardsUuids - [UUID!]
companyUuid - UUID
favorite - Boolean
Example
{
  "standardsUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ],
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "favorite": true
}
Types

IptSupplierComponentData

Fields
Input Field Description
componentUuid - UUID!
companyUuid - UUID!
description - String!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "description": "abc123"
}
Types

IptUpdateApiKeyData

Fields
Input Field Description
name - String
expiresAt - DateTime
isActive - Boolean
Example
{
  "name": "abc123",
  "expiresAt": "2007-12-03T10:15:30Z",
  "isActive": false
}
Types

IptUpdateCompanyCertificateData

Fields
Input Field Description
companyUuid - UUID!
fileUuid - UUID!
description - String!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "description": "xyz789"
}
Types

IptUpdateCompanyData

Fields
Input Field Description
orgname - String
shortname - String
inn - String
phone - String
email - String
description - String
address - String
siteUrl - String
timeZone - String
regionId - Int
companyTypeId - Int
Example
{
  "orgname": "abc123",
  "shortname": "abc123",
  "inn": "abc123",
  "phone": "xyz789",
  "email": "abc123",
  "description": "xyz789",
  "address": "xyz789",
  "siteUrl": "xyz789",
  "timeZone": "abc123",
  "regionId": 123,
  "companyTypeId": 987
}
Types

IptUpdateCompanyRepresentData

Fields
Input Field Description
regionId - Int
representationTypeId - Int
name - String
address - String
phone - String
Example
{
  "regionId": 987,
  "representationTypeId": 987,
  "name": "abc123",
  "address": "xyz789",
  "phone": "xyz789"
}
Types

IptUpdateComponentData

Fields
Input Field Description
parentComponentUuid - UUID
name - String
description - String
componentTypeId - Int
actualStatusId - Int
Example
{
  "parentComponentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "name": "abc123",
  "description": "abc123",
  "componentTypeId": 987,
  "actualStatusId": 123
}
Types

IptUpdateComponentModificationData

Fields
Input Field Description
modificationName - String
description - String
actualStatusId - Int
Example
{
  "modificationName": "abc123",
  "description": "xyz789",
  "actualStatusId": 987
}
Types

IptUpdateNameRoleData

Fields
Input Field Description
companyUuid - UUID!
roleId - Int!
langId - Int!
name - String!
Example
{
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "roleId": 987,
  "langId": 987,
  "name": "abc123"
}
Types

IptUpdatePassword

Fields
Input Field Description
oldPassword - String!
newPassword - String!
Example
{
  "oldPassword": "xyz789",
  "newPassword": "xyz789"
}
Types

IptUpdateServiceData

Fields
Input Field Description
name - String
description - String
regionId - Int
Example
{
  "name": "xyz789",
  "description": "xyz789",
  "regionId": 987
}
Types

IptUpdateStandardData

Fields
Input Field Description
name - String
description - String
publicationAt - NaiveDateTime
companyUuid - UUID
standardStatusId - Int
Example
{
  "name": "xyz789",
  "description": "xyz789",
  "publicationAt": NaiveDateTime,
  "companyUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "standardStatusId": 123
}
Types

IptUpdateUserCertificateData

Fields
Input Field Description
fileUuid - UUID!
description - String!
Example
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "description": "abc123"
}
Types

IptUpdateUserData

Fields
Input Field Description
email - String
firstname - String
lastname - String
secondname - String
username - String
phone - String
description - String
address - String
position - String
timeZone - String
regionId - Int
programId - Int
Example
{
  "email": "abc123",
  "firstname": "abc123",
  "lastname": "abc123",
  "secondname": "xyz789",
  "username": "abc123",
  "phone": "abc123",
  "description": "xyz789",
  "address": "abc123",
  "position": "abc123",
  "timeZone": "xyz789",
  "regionId": 987,
  "programId": 123
}
Types

IptUserAccessComponentData

Fields
Input Field Description
componentUuid - UUID!
userUuid - UUID!
typeAccessId - Int!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "typeAccessId": 123
}
Types

IptUserAccessServiceData

Fields
Input Field Description
serviceUuid - UUID!
userUuid - UUID!
typeAccessId - Int!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "typeAccessId": 123
}
Types

IptUserAccessStandardData

Fields
Input Field Description
standardUuid - UUID!
userUuid - UUID!
typeAccessId - Int!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "typeAccessId": 123
}
Types

IptUserCertificateData

Fields
Input Field Description
description - String!
filename - String!
Example
{
  "description": "xyz789",
  "filename": "xyz789"
}
Types

IptUserData

Fields
Input Field Description
email - String!
username - String!
password - String!
firstname - String
lastname - String
secondname - String
phone - String
description - String
address - String
position - String
timeZone - String
regionId - Int
programId - Int
typeAccessId - Int
Example
{
  "email": "abc123",
  "username": "xyz789",
  "password": "xyz789",
  "firstname": "abc123",
  "lastname": "xyz789",
  "secondname": "xyz789",
  "phone": "xyz789",
  "description": "abc123",
  "address": "xyz789",
  "position": "abc123",
  "timeZone": "xyz789",
  "regionId": 123,
  "programId": 987,
  "typeAccessId": 987
}
Types

IptUsersArg

Fields
Input Field Description
usersUuids - [UUID!]
subscribers - Boolean
favorite - Boolean
search - String
excludeUuids - [UUID!]
Example
{
  "usersUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ],
  "subscribers": false,
  "favorite": false,
  "search": "xyz789",
  "excludeUuids": [
    "c25ec13b-380b-48e4-ba36-fb6a5a140664"
  ]
}
Types

Keyword

Fields
Field Name Description
id - Int!
keyword - String!
Example
{"id": 987, "keyword": "xyz789"}
Types

Language

Fields
Field Name Description
id - Int!
lang - String!
langshort - String!
Example
{
  "id": 987,
  "lang": "xyz789",
  "langshort": "xyz789"
}
Types

License

Fields
Field Name Description
id - Int!
name - String!
keyword - String!
publicationAt - NaiveDateTime!
Example
{
  "id": 123,
  "name": "xyz789",
  "keyword": "xyz789",
  "publicationAt": NaiveDateTime
}
Types

LicenseData

Fields
Input Field Description
name - String!
keyword - String!
publicationAt - NaiveDateTime!
Example
{
  "name": "abc123",
  "keyword": "abc123",
  "publicationAt": NaiveDateTime
}
Types

ModificationParamWithTranslation

Fields
Field Name Description
modificationUuid - UUID!
param - ParamTranslateList!
value - String!
Example
{
  "modificationUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "param": ParamTranslateList,
  "value": "abc123"
}
Types

NaiveDateTime

Example
NaiveDateTime
Types

ParamTranslateList

Fields
Field Name Description
paramId - Int!
langId - Int!
paramname - String!
Example
{
  "paramId": 123,
  "langId": 987,
  "paramname": "xyz789"
}
Types

PermissionTranslateList

Fields
Field Name Description
typeAccessId - Int!
langId - Int!
name - String!
Example
{
  "typeAccessId": 987,
  "langId": 987,
  "name": "abc123"
}
Types

Program

Fields
Field Name Description
id - Int!
name - String!
Example
{"id": 987, "name": "xyz789"}
Types

RegionTranslateList

Fields
Field Name Description
regionId - Int!
langId - Int!
region - String!
Example
{
  "regionId": 123,
  "langId": 987,
  "region": "abc123"
}
Types

RepresentationTypeTranslateList

Fields
Field Name Description
representationTypeId - Int!
langId - Int!
representationType - String!
Example
{
  "representationTypeId": 987,
  "langId": 123,
  "representationType": "xyz789"
}
Types

RoleMemberAndRelatedData

Fields
Field Name Description
role - RoleMemberTranslateList!
permissions - [PermissionTranslateList!]!
Example
{
  "role": RoleMemberTranslateList,
  "permissions": [PermissionTranslateList]
}
Types

RoleMemberTranslateList

Fields
Field Name Description
roleMemberId - Int!
langId - Int!
name - String!
Example
{
  "roleMemberId": 987,
  "langId": 987,
  "name": "xyz789"
}
Types

ServiceAndRelatedData

Fields
Field Name Description
uuid - UUID!
name - String!
description - String!
ownerUser - ShowUserShort!
ownerCompany - ShowCompanyShort!
serviceStatus - ServiceStatusTranslateList!
region - RegionTranslateList!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
serviceParams - [ServiceParamWithTranslation!]!
Arguments
sort - IptSort
paginate - IptPaginate
paramsCount - Int!
files - [ShowFileRelatedData!]!
Arguments
sort - IptSort
paginate - IptPaginate
filesCount - Int!
serviceSpecs - [SpecTranslateList!]!
Arguments
paginate - IptPaginate
serviceKeywords - [Keyword!]!
Arguments
paginate - IptPaginate
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "name": "xyz789",
  "description": "abc123",
  "ownerUser": ShowUserShort,
  "ownerCompany": ShowCompanyShort,
  "serviceStatus": ServiceStatusTranslateList,
  "region": RegionTranslateList,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime,
  "serviceParams": [ServiceParamWithTranslation],
  "paramsCount": 987,
  "files": [ShowFileRelatedData],
  "filesCount": 987,
  "serviceSpecs": [SpecTranslateList],
  "serviceKeywords": [Keyword]
}
Types

ServiceParamWithTranslation

Fields
Field Name Description
serviceUuid - UUID!
param - ParamTranslateList!
value - String!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "param": ParamTranslateList,
  "value": "abc123"
}
Types

ServiceStatusTranslateList

Fields
Field Name Description
serviceStatusId - Int!
langId - Int!
name - String!
Example
{
  "serviceStatusId": 987,
  "langId": 123,
  "name": "abc123"
}
Types

ShowCompanyShort

Fields
Field Name Description
uuid - UUID!
shortname - String!
inn - String!
description - String!
imageFile - DownloadFile!
region - RegionTranslateList!
companyType - CompanyTypeTranslateList!
typeAccess - TypeAccessTranslateList!
isSupplier - Boolean!
isFollowed - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "shortname": "abc123",
  "inn": "abc123",
  "description": "xyz789",
  "imageFile": DownloadFile,
  "region": RegionTranslateList,
  "companyType": CompanyTypeTranslateList,
  "typeAccess": TypeAccessTranslateList,
  "isSupplier": true,
  "isFollowed": true,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime
}
Types

ShowComponentShort

Fields
Field Name Description
uuid - UUID!
name - String!
description - String!
imageFile - DownloadFile!
ownerUser - ShowUserShort!
typeAccess - TypeAccessTranslateList!
componentType - ComponentTypeTranslateList!
actualStatus - ActualStatusTranslateList!
isBase - Boolean!
isFollowed - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
licenses - [License!]!
files - [DownloadFile!]!
Arguments
paginate - IptPaginate
images - Boolean
componentSuppliers - [ComponentSupplierRelatedData!]!
Arguments
paginate - IptPaginate
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "name": "abc123",
  "description": "xyz789",
  "imageFile": DownloadFile,
  "ownerUser": ShowUserShort,
  "typeAccess": TypeAccessTranslateList,
  "componentType": ComponentTypeTranslateList,
  "actualStatus": ActualStatusTranslateList,
  "isBase": true,
  "isFollowed": false,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime,
  "licenses": [License],
  "files": [DownloadFile],
  "componentSuppliers": [ComponentSupplierRelatedData]
}
Types

ShowFileRelatedData

Fields
Field Name Description
uuid - UUID!
filename - String!
revision - Int!
commitMsg - String!
parentFileUuid - UUID!
ownerUser - ShowUserShort!
contentType - String!
filesize - Int!
program - Program!
hash - String!
sha256Hash - String!
downloadUrl - String!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filename": "xyz789",
  "revision": 123,
  "commitMsg": "abc123",
  "parentFileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "ownerUser": ShowUserShort,
  "contentType": "xyz789",
  "filesize": 123,
  "program": Program,
  "hash": "abc123",
  "sha256Hash": "abc123",
  "downloadUrl": "xyz789",
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime
}
Types

ShowNotification

Fields
Field Name Description
id - Int!
notification - String!
degreeImportance - DegreeImportanceTranslateList!
createdAt - NaiveDateTime!
isRead - Boolean!
Example
{
  "id": 123,
  "notification": "abc123",
  "degreeImportance": DegreeImportanceTranslateList,
  "createdAt": NaiveDateTime,
  "isRead": true
}
Types

ShowServiceShort

Fields
Field Name Description
uuid - UUID!
name - String!
description - String!
ownerUser - ShowUserShort!
ownerCompany - ShowCompanyShort!
serviceStatus - ServiceStatusTranslateList!
updatedAt - NaiveDateTime!
files - [DownloadFile!]!
Arguments
paginate - IptPaginate
images - Boolean
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "name": "abc123",
  "description": "abc123",
  "ownerUser": ShowUserShort,
  "ownerCompany": ShowCompanyShort,
  "serviceStatus": ServiceStatusTranslateList,
  "updatedAt": NaiveDateTime,
  "files": [DownloadFile]
}
Types

ShowStandardShort

Fields
Field Name Description
uuid - UUID!
name - String!
description - String!
publicationAt - NaiveDateTime!
imageFile - DownloadFile!
ownerCompany - ShowCompanyShort!
standardStatus - StandardStatusTranslateList!
updatedAt - NaiveDateTime!
isFollowed - Boolean!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "name": "abc123",
  "description": "abc123",
  "publicationAt": NaiveDateTime,
  "imageFile": DownloadFile,
  "ownerCompany": ShowCompanyShort,
  "standardStatus": StandardStatusTranslateList,
  "updatedAt": NaiveDateTime,
  "isFollowed": true
}
Types

ShowUserAndRelatedData

Fields
Field Name Description
uuid - UUID!
firstname - String!
lastname - String!
secondname - String!
username - String!
description - String!
position - String!
imageFile - DownloadFile!
region - RegionTranslateList!
program - Program!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
certificates - [UserCertificateAndFile!]!
subscribers - Int!
isFollowed - Boolean!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "firstname": "abc123",
  "lastname": "abc123",
  "secondname": "xyz789",
  "username": "xyz789",
  "description": "abc123",
  "position": "xyz789",
  "imageFile": DownloadFile,
  "region": RegionTranslateList,
  "program": Program,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime,
  "certificates": [UserCertificateAndFile],
  "subscribers": 123,
  "isFollowed": true
}
Types

ShowUserShort

Fields
Field Name Description
uuid - UUID!
firstname - String!
lastname - String!
username - String!
imageFile - DownloadFile!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "firstname": "xyz789",
  "lastname": "xyz789",
  "username": "abc123",
  "imageFile": DownloadFile
}
Types

SlimCompany

Fields
Field Name Description
uuid - UUID!
shortname - String!
isSupplier - Boolean!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "shortname": "abc123",
  "isSupplier": true
}
Types

SlimUser

Fields
Field Name Description
uuid - UUID!
username - String!
programId - Int!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "username": "abc123",
  "programId": 123
}
Types

SpecPath

Fields
Field Name Description
specId - Int!
langId - Int!
path - String!
depth - Int!
Example
{
  "specId": 123,
  "langId": 987,
  "path": "abc123",
  "depth": 987
}
Types

SpecTranslateList

Fields
Field Name Description
specId - Int!
langId - Int!
spec - String!
parentSpec - SpecTranslateList!
Example
{
  "specId": 987,
  "langId": 123,
  "spec": "xyz789",
  "parentSpec": SpecTranslateList
}
Types

StandardAndRelatedData

Fields
Field Name Description
uuid - UUID!
parentStandardUuid - UUID!
name - String!
description - String!
publicationAt - NaiveDateTime!
imageFile - DownloadFile!
ownerUser - ShowUserShort!
ownerCompany - ShowCompanyShort!
typeAccess - TypeAccessTranslateList!
standardStatus - StandardStatusTranslateList!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
standardFiles - [ShowFileRelatedData!]!
standardSpecs - [SpecTranslateList!]!
standardKeywords - [Keyword!]!
subscribers - Int!
isFollowed - Boolean!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "parentStandardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "name": "abc123",
  "description": "xyz789",
  "publicationAt": NaiveDateTime,
  "imageFile": DownloadFile,
  "ownerUser": ShowUserShort,
  "ownerCompany": ShowCompanyShort,
  "typeAccess": TypeAccessTranslateList,
  "standardStatus": StandardStatusTranslateList,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime,
  "standardFiles": [ShowFileRelatedData],
  "standardSpecs": [SpecTranslateList],
  "standardKeywords": [Keyword],
  "subscribers": 987,
  "isFollowed": false
}
Types

StandardStatusTranslateList

Fields
Field Name Description
standardStatusId - Int!
langId - Int!
name - String!
Example
{
  "standardStatusId": 987,
  "langId": 987,
  "name": "abc123"
}
Types

String

Description

The String scalar type represents textual data, represented as UTF-8 character sequences. The String type is most often used by GraphQL to represent free-form human-readable text.

Example
"xyz789"
Types

ToObject

Values
Enum Value Description

COMPANY

COMPONENT

SERVICE
Example
"COMPANY"
Types

Token

Fields
Field Name Description
bearer - String
Example
{"bearer": "xyz789"}
Types

TypeAccessTranslateList

Fields
Field Name Description
typeAccessId - Int!
langId - Int!
name - String!
Example
{
  "typeAccessId": 123,
  "langId": 123,
  "name": "xyz789"
}
Types

UUID

Example
"c25ec13b-380b-48e4-ba36-fb6a5a140664"
Types

UploadFile

Fields
Field Name Description
fileUuid - UUID!
filename - String!
uploadUrl - String!
Example
{
  "fileUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "filename": "xyz789",
  "uploadUrl": "abc123"
}
Types

UserAccessComponentAndRelatedData

Fields
Field Name Description
componentUuid - UUID!
user - ShowUserShort!
permission - PermissionTranslateList!
isEnabled - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
Example
{
  "componentUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "user": ShowUserShort,
  "permission": PermissionTranslateList,
  "isEnabled": false,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime
}
Types

UserAccessServiceAndRelatedData

Fields
Field Name Description
serviceUuid - UUID!
user - ShowUserShort!
permission - PermissionTranslateList!
isEnabled - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
Example
{
  "serviceUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "user": ShowUserShort,
  "permission": PermissionTranslateList,
  "isEnabled": true,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime
}
Types

UserAccessStandardAndRelatedData

Fields
Field Name Description
standardUuid - UUID!
user - ShowUserShort!
permission - PermissionTranslateList!
isEnabled - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
Example
{
  "standardUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "user": ShowUserShort,
  "permission": PermissionTranslateList,
  "isEnabled": false,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime
}
Types

UserAndRelatedData

Fields
Field Name Description
uuid - UUID!
email - String!
firstname - String!
lastname - String!
secondname - String!
username - String!
phone - String!
description - String!
address - String!
position - String!
timeZone - String!
imageFile - DownloadFile!
region - RegionTranslateList!
program - Program!
typeAccess - TypeAccessTranslateList!
isEmailVerified - Boolean!
createdAt - NaiveDateTime!
updatedAt - NaiveDateTime!
certificates - [UserCertificateAndFile!]!
subscribers - Int!
companiesCount - Int!
componentsCount - Int!
standardsCount - Int!
favCompaniesCount - Int!
favComponentsCount - Int!
favStandardsCount - Int!
favUsersCount - Int!
Example
{
  "uuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "email": "xyz789",
  "firstname": "xyz789",
  "lastname": "xyz789",
  "secondname": "abc123",
  "username": "abc123",
  "phone": "xyz789",
  "description": "abc123",
  "address": "abc123",
  "position": "xyz789",
  "timeZone": "abc123",
  "imageFile": DownloadFile,
  "region": RegionTranslateList,
  "program": Program,
  "typeAccess": TypeAccessTranslateList,
  "isEmailVerified": false,
  "createdAt": NaiveDateTime,
  "updatedAt": NaiveDateTime,
  "certificates": [UserCertificateAndFile],
  "subscribers": 123,
  "companiesCount": 987,
  "componentsCount": 123,
  "standardsCount": 987,
  "favCompaniesCount": 987,
  "favComponentsCount": 123,
  "favStandardsCount": 123,
  "favUsersCount": 123
}
Types

UserCertificateAndFile

Fields
Field Name Description
file - DownloadFile!
userUuid - UUID!
description - String!
Example
{
  "file": DownloadFile,
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "description": "abc123"
}
Types

UserToken

Fields
Field Name Description
userUuid - UUID!
token - String!
createdAt - NaiveDateTime!
expirationAt - NaiveDateTime!
Example
{
  "userUuid": "c25ec13b-380b-48e4-ba36-fb6a5a140664",
  "token": "xyz789",
  "createdAt": NaiveDateTime,
  "expirationAt": NaiveDateTime
}
Documentation by Anvil SpectaQL
